ESP8266User Manual
ESP-WROOM-02 WiFiModule
FOR OEM OR INTEGRATORS ONLY: This module is limited to OEM
installation only and must not be sold to end-users.
Disclaimer and Copyright Notice
Information in this document, including URL references, is subject to change without
notice.
THIS DOCUMENT IS PROVIDED "AS IS" WITH NO WARRANTIES
WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY,
NONINFRINGEMENT, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY
WARRANTY
OTHERWISE
SPECIFICATION OR SAMPLE. All liability, including liability for infringement of
any proprietary rights, relating to use of information in this document is disclaimed.
No licenses express or implied, by estoppel or otherwise, to any intellectual property
rights are granted herein.
The Wi-Fi Alliance Member Logo is a trademark of the Wi-Fi Alliance.
All trade names, trademarks and registered trademarks mentioned in this document
are property of their respective owners, and are hereby acknowledged.
Copyright © 2013 Espressif Systems Inc. All rights reserved.
Caution: Changes or modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment.
USER MANUAL
[
] CONFIDENTIAL
[
] INTERNAL
[ ] PUBLIC
ARISING
1 / 13Espressif SystemsJune 19, 2014
OUT
OF
ANY
PROPOSAL,
Advertisement
Table of Contents
Related Manuals for Espressif Systems ESP-WROOM-02
Summary of Contents for Espressif Systems ESP-WROOM-02
- Page 1 The Wi-Fi Alliance Member Logo is a trademark of the Wi-Fi Alliance. All trade names, trademarks and registered trademarks mentioned in this document are property of their respective owners, and are hereby acknowledged. Copyright © 2013 Espressif Systems Inc. All rights reserved. Caution: Changes or modifications not expressly approved by the manufacturer could void the ...
- Page 2 ESP8266User Manual This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2 / 13Espressif SystemsJune 19, 2014...
-
Page 3: Table Of Contents
ESP8266User Manual 2. Table of Contents 2. Table of Contents ....................... 3 1. Foreword ........................ 4 2. FCC RF exposure requirements ................. 5 2.1. Standards and Regulatory Compliance .............. 5 2.1.1. Standards and certification ................ 5 2.1.2. FCC certification requirements ................ 5 2.1.3. FCC RF exposure requirements ................ 7 3. Download Tools ...................... 9 3.1. XTCOM_UTIL ...................... 9 3.2. ESP_FLASH_DOWNLOAD ................... 1 2 3 / 13Espressif SystemsJune 19, 2014... -
Page 4: Foreword
ESP8266User Manual Foreword This manual mainly introduces how to use ESP8266‐based SDK for Internet of Things, including virtual machine installation, development tool usage, SDK software development kit etc. This module is limited to OEM installation only and must not be sold to end‐users. OEM integrators must be instructed to ensure that the end‐user has no manual instructions to remove or install the device. The end‐user can not remove or install this module to any other devices. 4 / 13Espressif SystemsJune 19, 2014... -
Page 5: Fcc Rf Exposure Requirements
ESP8266User Manual FCC RF exposure requirements 2.1. Standards and Regulatory Compliance 2.1.1. Standards and certification The EUT conforms to the following standards and certification requirements: 802.11 b/g/n FCC ❒ 47 CFR Part 1 ‐ RF radiation exposure limits ❒ 47 CFR Part 2 ‐ Equipment authorization ❒ 47 CFR Part C ‐ WIFI 2.1.2. FCC certification requirements According to the definition of mobile and fixed device is described in Part 2.1091(b), this device is a mobile device. ... - Page 6 ESP8266User Manual transmitter 6. The host end product must include a user manual that clearly defines operating requirements and conditions that must be observed to ensure compliance with current FCC RF exposure guidelines. For portable devices, in addition to the conditions 3 through 6 described above, a separate approval is required to satisfy the SAR requirements of FCC Part 2.1093 If the device is used for other equipment that separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. For this device, OEM integrators must be provided with labeling instructions of finished products. Please refer to KDB784748 D01 v08, section 8. Page 6/7 last two paragraphs: A certified modular has the option to use a permanently affixed label, or an electronic label. For a permanently affixed label, the module must be labelled with ...
-
Page 7: Fcc Rf Exposure Requirements
ESP8266User Manual the equipment. In cases where the manual is provided only in a form other than paper, such as on a computer disk or over the Internet, the information required by this section may be included in the manual in that alternative form, provided the user can reasonably be expected to have the capability to access information in that form. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ... - Page 8 ESP8266User Manual requirements. 8 / 13Espressif SystemsJune 19, 2014...
-
Page 9: Download Tools
ESP8266User Manual 3. Download Tools 3.1. XTCOM_UTIL Double‐click the icon to run the download tool to download the compiled *.bin files onto the SPI Flash on the ESP8266 motherboard. Set the jumper on the motherboard as MTDO：0，GPIO0：0，GPIO2：1, then it will enter download mode. Steps are as follows: Step 1: set serial port Step 2: select the right serial port number and open Step 3: connect 9 / 13Espressif SystemsJune 19, 2014... - Page 10 ESP8266User Manual Step 4: download the image file Step 5: select and download the bin file which you are going to burn into the flash Note: Program Address Offset varies in accordance with bin file. For example, the corresponding Program Address Offset for eagle.app.v6.flash.bin is 0x0000. Please refer to bin directory descriptions in "4.2 Directory Structure". Step 6: re‐connect After ...
- Page 11 ESP8266User Manual serial port and repeat Step 2 and Step 3. Step 7: select and download next bin file which you are going to burn into the flash, for example, eagle.app.v6.irom0text.bin. Note: the corresponding Program Address Offset for eagle.app.v6.irom0text.bin is 0x40000. Please refer to bin directory descriptions in "4.2 Directory Structure". Step 8: close serial port After the downloading, users can check and print relevant information with SecureCRT. Set the jumper on the motherboard as MTDO：0，GPIO0：1，GPIO2：1, then it will enter operatings mode. Note: please disconnect the power when setting the jumpers. 11 / 13Espressif SystemsJune 19, 2014...
-
Page 12: Esp_Flash_Download
ESP8266User Manual 3.2. ESP_FLASH_DOWNLOAD Espressif also provides the tool "ESP_FLASH_DOWNLOAD" for users to burn several bin files altogether at once, and download several complied *.bin files at a time into the SPI Flash on the ESP8266 motherboard. “ESP_FLASH_DOWNLOAD” introduction： （1） Bin‐Select Area: Choose bins to burn，and burn them in corresponding address. ... - Page 13 ESP8266User Manual （3） Mac Address：Mac address of ESP8266. Also set the jumper on the motherboard as MTDO：0，GPIO0：0，GPIO2：1, then it will enter download mode. Steps are as follows: (1) See the red boxes in the picture above, select the bin file to be burned ->fill in the path ->check burning options. (2) Set COM port and baud rate. (3) Click "START" to start downloading. (4) After the downloading, disconnect the power for the motherboard, and change the jumper into operation mode.
