IP Office
Installation Manual
40DHB0002UKCL – Issue 9 (28 October 2003)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40DHB0002UKCL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avaya 40DHB0002UKCL

Summary of Contents for Avaya 40DHB0002UKCL

  • Page 1 IP Office Installation Manual 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 2: Table Of Contents

    Rear View ......................................25 IP400 WAN3................................26 Front View......................................26 Rear View ......................................26 IP400 Analog Trunk 16 ............................27 Front View......................................27 Rear View ......................................27 Country Variants .............................28 Page 2 - Contents IP Office Installation Manual 40DHB0002UKCL – Issue 9 (28 October 2003)
  • Page 3 Further Information and Product Updates......................60 Support Telephone Numbers ................................. 60 Regulatory Instructions for Use ...........................61 IP Office Operation in Australia ..............................61 IP Office Operation in Canada ............................... 61 IP Office Installation Manual Contents - Page 3 40DHB0002UKCL – Issue 9 (28 October 2003)
  • Page 4 MIBs Supported ....................................82 Trap Generation....................................83 MIB Loading......................................83 HP OpenView Network Node Manager 6.41 and earlier: ..................... 83 CastleRock SNMPc 5.1.6c and earlier:............................84 Index ................................85 Page 4 - Contents IP Office Installation Manual 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 5: Introduction

    IP Office training courses. Ensure that you have read and understood this manual before beginning installation. For installation instructions for the Avaya IP Office - Small Office Edition, refer to the separate Installation Manual (available on CD).

  • Page 6: General

    The auto-negotiating 10/100 BaseT LAN hub provides access to networks and/or up to eight IP telephones. The DT ports support Avaya 2000 series telephones. DT ports are set to A-Law PCM encoding at default but can be programmed to µ-Law PCM encoding.

  • Page 7: Ip401 Compact Office - Front View

    Port connections • DT Ports: DT ports are used for connection to Avaya 2000 series telephones (see page 5) and support either A-Law or µ-Law PCM encoding (default A-Law). Using DT Line Cords (see page 68) and standard structured wiring, these RJ45 ports can be extended to the required telephone location.

  • Page 8: Ip401 Compact Office - Rear View

    Port Pinouts and Cables For Port Pinouts and Cables, refer to pages 63 and 67 respectively. Page 8 - IP401 Compact Office Platform IP Office Installation Manual IP401 Compact Office - Rear View 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 9: Typical Configuration

    A customer requiring a voice and data solution for a warehousing facility remote from a regional office. Three administrators and two pickers staff the warehouse. This configuration provides support for four Avaya 2000 series digital telephones, one for each of the administrators, leaving a spare port for future growth. Up to four analog telephones (POTS), two of which support a DECT wireless solution to allow the pickers freedom of movement, with one of the remaining ports being used for a fax machine.

  • Page 10: Ip403 Office Platform

    • DT ports - support Avaya 2000 series telephones. • DS ports - support Avaya 6400, 2420 series and/or Avaya 4400 series telephones. Both ports can be set for either µ-Law or A-Law PCM encoding. At default DT ports are set to A-Law and DS ports are set to µ-Law.

  • Page 11: Ip403 Office - Front View

    (POTs) Port connections • DT/DS Ports - DT ports are for connection to Avaya 2000 series telephones (see page 5). - DS ports are for connection to Avaya 4400, 2420 and/or 6400 series telephones (see page 5). At default DT ports are set to A-Law PCM encoding and DS ports to either A-Law or µ- Law PCM encoding (see page 28).

  • Page 12: Ip403 Office - Rear View

    • For Port Pinouts and Cables, refer to pages 63 and 67 respectively. Functional Earth For Functional Earth connections see page 35. Page 12 - IP403 Office Platform IP Office Installation Manual IP403 Office - Rear View 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 13: Typical Configuration

    A customer with sophisticated telephony requirements, needing 30 exchange lines and 80 Display Terminals. This configuration provides support for 98 Avaya 20 series digital telephones (18 spare for growth) and a single Primary Rate ISDN connection. If growth beyond 18 users or additional line capacity were anticipated, the IP406 Office would be considered more appropriate.

  • Page 14: Ip406 Office Platform

    5, 10 and 20 channel variants. • Dual Modem Module Allows termination of two simultaneous analog modem calls up to and including 56kbps. Page 14 - IP406 Office Platform IP Office Installation Manual General 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 15: Ip406 Office - Front View

    Analog 4 is supplied with four red CAT5E cables. IP406 Office BRI 16 is supplied with eight red CAT5E cables. For Port Pinouts and Cables, refer to pages 63 and 67 respectively. IP Office Installation Manual IP406 Office Platform - Page 15 40DHB0002UKCL – Issue 9 (28 October 2003) IP406 Office - Front View...

  • Page 16: Ip406 Office - Rear View

    • For Port Pinouts and Cables, refer to pages 63 and 67 respectively. Functional Earth For Functional Earth connections see page 35. Page 16 - IP406 Office Platform IP Office Installation Manual IP406 Office - Rear View 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 17: Typical Configurations

    - C + 24V DC EXPANSION DC I/P - C + AUDIO 24V DC Slot A Slot B IP Office Installation Manual IP406 Office Platform - Page 17 40DHB0002UKCL – Issue 9 (28 October 2003) IP406 Office - Rear View...

  • Page 18: Ip412 Office Platform

    5, 10, 20 and 30 channel variants. The IP412 Office can have two VCMs (of any type). • Dual Modem Module Allows termination of two simultaneous analog modem calls at speeds up to and including 56kbps (V.90). Page 18 - IP412 Office Platform IP Office Installation Manual General 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 19: Ip412 Office - Front View

    IP412 Office DT PRI60 E1 & PRI48 T1 are supplied with two red CAT5E cables. For Port Pinouts and Cables, refer to pages 63 and 67 respectively. IP Office Installation Manual IP412 Office Platform - Page 19 40DHB0002UKCL – Issue 9 (28 October 2003) IP412 Office - Front View...

  • Page 20: Ip412 Office - Rear View

    For Port Pinouts and Cables, refer to pages 63 and 67 respectively. Functional Earth For Functional Earth connections see page 35. Page 20 - IP412 Office Platform IP Office Installation Manual IP412 Office - Rear View 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 21: Typical Configurations

    - C + 24V DC EXPANSION DC I/P - C + AUDIO 24V DC Slot B Slot A IP Office Installation Manual IP412 Office Platform - Page 21 40DHB0002UKCL – Issue 9 (28 October 2003) IP412 Office - Rear View...
  • Page 22 - IP400 iPhoneManager Pro RFA 40 (50+40 = 90) EXPANSION DC I/P - C + W AN AUDIO 24V DC Slot A Slot B Page 22 - IP412 Office Platform IP Office Installation Manual IP412 Office - Rear View 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 23: Expansion Modules

    (1-16). Port connections • DT ports are used for connection to Avaya 2000 series telephones (see page 5) and support either A-Law or µ-Law PCM encoding. Both DT and DS ports can be set for either µ-Law or A-Law PCM encoding. At default both types of port are set to µ-Law but can be switched, in software, to A-Law (refer to the Administration Manager Manual for details).

  • Page 24: Ip400 Digital Stations 16/30

    The IP400 Digital Station Expansion Module similar to the IP400 Digital Terminal Expansion Module (see page 23) with the exception that the Ports are labeled DS not DT and support Avaya 6400, 2420 or 4400 series telephones. IP400 Phone 8/16/30...

  • Page 25: Ip400 So8

    IP400 So8 is supplied with one blue Expansion Interconnect cable. For Port Pinouts and Cables, refer to pages 63 and 67 respectively. Functional Earth For Functional Earth connections see page 35. IP Office Installation Manual Expansion Modules - Page 25 40DHB0002UKCL – Issue 9 (28 October 2003) IP400 So8...

  • Page 26: Ip400 Wan3

    IP400 WAN3 is supplied with one green LAN Interconnect cable. For Port Pinouts and Cables, refer to pages 63 and 67 respectively. Functional Earth For Functional Earth connections see page 35. Page 26 - Expansion Modules IP Office Installation Manual IP400 WAN3 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 27: Ip400 Analog Trunk 16

    IP400 Analog Trunk 16 is supplied with one blue Expansion Interconnect cable. For Port Pinouts and Cables, refer to pages 63 and 67 respectively. IP Office Installation Manual Expansion Modules - Page 27 40DHB0002UKCL – Issue 9 (28 October 2003) IP400 Analog Trunk 16...

  • Page 28: Country Variants

    CH, CALA µ IP412 Office (No Trunks) 700210784 µ IP412 Office PRI 24 T1 700184740 µ IP412 Office PRI 48 T1 700184757 Page 28 - Country Variants IP Office Installation Manual IP400 Office Systems 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 29: Integral Module Kits

    2. PRI T1trunks support both ISDN and Analog emulation. The default setting is 23B+1D and is switchable in the installation software to become a 24B trunk. IP Office Installation Manual Country Variants - Page 29 40DHB0002UKCL – Issue 9 (28 October 2003) Integral Module Kits...

  • Page 30: Power Supplies

    700213390 IP400 Power Lead USA Pack 10 700177558 IP400 Power Lead European CEE7/7 700254519 IP400 Power Lead European CEE7/7 Pack 10 700177559 Page 30 - Country Variants IP Office Installation Manual Power Supplies 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 31: Ip Office Rack Mounting Kits

    IP400 WAN3 700185028 IP400 WAN3 10/100 700262009 Note: For countries outside the Americas/CALA, use ROW variant unless stated otherwise. IP Office Installation Manual Country Variants - Page 31 40DHB0002UKCL – Issue 9 (28 October 2003) IP Office Rack Mounting Kits...

  • Page 32: Preparing For Installation

    – IP Office Manager Application Manual (supplied on CD with system). – IP Office Feature Key (where software that requires a Licence Key is to be installed). Page 32 - Preparing for Installation IP Office Installation Manual Introduction 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 33: Space Requirements

    4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. SAVE THESE INSTRUCTIONS. IP Office Installation Manual Preparing for Installation - Page 33 40DHB0002UKCL – Issue 9 (28 October 2003) Space requirements...

  • Page 34: Power Supply Requirements

    – UPS Equipment : The use of UPS's to support the IP Office system during mains power failure is highly recommended. Such equipment also provides mains conditioning. Contact Avaya for details of preferred and tested suppliers and models. Page 34 - Preparing for Installation...

  • Page 35: Grounding

    2. Connect, using a fastening that satisfies local regulations, the other end of the wire to the approved ground, such as building steel or an earthed metal cold water pipe. IP Office Installation Manual Preparing for Installation - Page 35 40DHB0002UKCL – Issue 9 (28 October 2003) Grounding...

  • Page 36: Out Of Building Telephone Installations

    Avaya IP400 Phone Barrier Boxes must only be used in conjunction with UL Listed Avaya IP400 Phone 8/16/30 modules. Where more than three Avaya IP400 Phone Barrier boxes are to be used they must be rack mounted (see page 37). For non-rack mounting of the Avaya IP400 Phone Barrier Box, proceed as follows: Notes: 1.

  • Page 37: Rack Mounting Barrier Boxes

    Out of Building Telephone Installations - Page 37 Rack Mounting Barrier Boxes Where more than three Avaya IP400 Phone Barrier Boxes are to be used they must be rack mounted. Rack mounting kits are available (SAP Code 700293905) for mounting eight Avaya IP400 Phone Barrier Boxes.

  • Page 38: Installing A New System

    Report any errors or omissions to the dealer who supplied the equipment. 5. Ensure you read and understand any documentation included with any item. Page 38 - Installing a New System IP Office Installation Manual Unpacking 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 39: Initial Assembly

    8. Connect the individual Lump-in-Line PSU to each IP Office module and switch on*. 9. From the Administrator CD (see page 47), install on your PC the software required to configure and manage your Avaya IP Office (see page 46). *IMPORTANT: Power on the Expansion Modules first.

  • Page 40: Installation Of Integral Modules

    9. Replace cover and secure with the seven fixing screws. CAUTION: While installing, ensure that you wear a ground wrist strap that is connected to a suitable grounding point. Page 40 - Installing a New System IP Office Installation Manual Initial Assembly 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 41: Installation Of Voice Compression Modules (Vcm)

    5. Replace cover and secure with the seven fixing screws. CAUTION: While installing, ensure that you wear a ground wrist strap that is connected to a suitable grounding point. IP Office Installation Manual Installing a New System - Page 41 40DHB0002UKCL – Issue 9 (28 October 2003) Initial Assembly...

  • Page 42: Dual Modem Module

    5. Replace the cover and secure with the seven fixing screws. CAUTION: While installing, ensure that you wear a ground wrist strap that is connected to a suitable grounding point. Page 42 - Installing a New System IP Office Installation Manual Initial Assembly 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 43: Rack Mounting Assembly Instructions

    Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips). See page 35. IP Office Installation Manual Installing a New System - Page 43 40DHB0002UKCL – Issue 9 (28 October 2003) Initial Assembly...

  • Page 44: Ip401 Compact Office Wall Mounting

    Re-position the IP401 Compact Office unit and secure with a No. 8 Panhead (or similar) through the slot of the Z-bracket. Page 44 - Installing a New System IP Office Installation Manual IP401 Compact Office Wall Mounting 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 45: Ip401 Expansion And Installation Of Integral Modules

    CAUTION: While installing modules, ensure that you wear aground wrist strap that is connected to a suitable grounding point. IP Office Installation Manual Installing a New System - Page 45 40DHB0002UKCL – Issue 9 (28 October 2003) IP401 Expansion and Installation of Integral Modules...

  • Page 46: Basic System Programming

    Network Manager to obtain the required IP settings. For IP operation the IP Office requires a static IP address including a subnet mask and default gateway value. Page 46 - Basic System Programming IP Office Installation Manual Introduction 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 47: Initial Programming

    6. Installation runs and on completion select Restart now and click Finish twice. The IP Office Administration suite of applications is now installed on your PC and you are now ready to configure your Avaya IP Office. You have two choices: Using the IP Office Installation Wizard: This application is recommended for first time installers.

  • Page 48: Using The Ip Office Manager Application

    Help files and/or the Manager Application Manual. Press F1 to access the Help files. Note: To activate Voicemail Lite, from the Program file, select IP Office and Voicemail and click on Run. Page 48 - Basic System Programming IP Office Installation Manual Initial Programming 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 49: Software Upgrades

    IP403 and to upgrade to all Software Levels on an IP401, IP406 and IP412, perform the following: Right click on Start and select Explore | Program Files | Avaya | IP Office Manager. Save all xxx.cfg files (where xxx is the name of the configuration) to a separate safe location.
  • Page 50 12. Do not open the Manager application at this stage. 13. Using the Explorer on your PC open up the Program Files | Avaya | IP Office | Manager | IP403V1_99 folder. This will contain a file called ip403.bin. This file is version 1.99 of the IP Office 403 firmware and contains the loader that is necessary to...

  • Page 51: Telephone Installation

    IP Office module, an RJ11/RJ45 adapter should be used. Similarly, the structured wiring should terminate in RJ11 sockets. IP Office Installation Manual Telephone Installation - Page 51 40DHB0002UKCL – Issue 9 (28 October 2003) Checking Telephones...

  • Page 52: Connecting & Checking Two-Wire Telephones

    Where E911 statuary requirements for discrete location identification of a power fail phone are required on the transmitted CLI, ensure that the relevant installation programming is completed. Page 52 - Telephone Installation IP Office Installation Manual Checking Telephones 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 53: Wall Mounting 2000 Series Telephones

    20AT Telephones (Not to Round head screws. (Not to scale) scale) – Two wall plugs. – Drill and drill bit. – Screwdriver. IP Office Installation Manual Telephone Installation - Page 53 40DHB0002UKCL – Issue 9 (28 October 2003) Wall Mounting 2000 Series Telephones...
  • Page 54 Page 54 - Wall Mounting 2000 Series Telephones Telephone Installation Page 54 - Telephone Installation IP Office Installation Manual Wall Mounting 2000 Series Telephones 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 55: Wall Mounting 44/4600, 2420 & 6400 Series Telephones

    (supplied on the CD with the IP Office system). IP Office Installation Manual Telephone Installation - Page 55 40DHB0002UKCL – Issue 9 (28 October 2003) Wall Mounting 44/4600, 2420 & 6400 Series Telephones...

  • Page 56: System Handover

    – Has the mains supply (and any UPS if fitted) been tested? – Where VoIP is to be deployed have the appropriate network design criteria and QoS mechanisms been applied as per the Avaya planning guidelines. Wiring : – Have the trunk modules and Analog Trunk 16, where equipped, been fitted with the appropriate functional/protective grounds (see page 35).

  • Page 57: Safety And Homologation Statements

    WARNING The Avaya IP400 Office units are intended to be installed by 'Service Personnel' and it is the responsibility of the Service Personnel to ensure that all subsidiary interconnected equipment is wired correctly and also meet the safety requirements of IEC60950 or UL60950 where applicable.

  • Page 58: Electromagnetic Interference Information

    In a domestic environment, IP401 Compact Office, IP403, IP406, IP412 and all Expansion Modules may cause radio interference in which case the user may be requested to take adequate measures. Page 58 - Safety and Homologation Statements IP Office Installation Manual Electromagnetic Interference Information 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 59: Trunk Interface Modules

    Trunk 4 (LS) IP403 Office DS IP406 Office IP412 Office* See page 29 for country specific variant SAP codes. IP Office Installation Manual Safety and Homologation Statements - Page 59 40DHB0002UKCL – Issue 9 (28 October 2003) Trunk Interface Modules...

  • Page 60: Further Information And Product Updates

    Support Telephone Numbers For initial help and support, contact your distributor/supplier. The following contact points are for Avaya authorized partners. In the USA only, Avaya provides a toll-tree Customer Helpline 24 hours a day: Name: Avaya Technical Support Organization (TSO)

  • Page 61: Regulatory Instructions For Use

    Safety and Homologation Statements Regulatory Instructions for Use - Page 61 Regulatory Instructions for Use Any changes or modifications not expressly approved by Avaya ECS Ltd could void the user's authority to operate the equipment. IP Office Operation in Australia...

  • Page 62: Ip Office Operation In Eu

    RENs, contact the local telephone company to determine the maximum REN for the calling area. Page 62 - Safety and Homologation Statements IP Office Installation Manual Regulatory Instructions for Use 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 63: Technical Data

    ISDN Port – BRI (RJ45) Pin No. Description Signal Direction Pin 8 Pin 1 Transmit Data (Tx-A) Receive Data (Rx-A) Receive Data (Rx-B) Transmit Data (Tx-B) IP Office Installation Manual Technical Data - Page 63 40DHB0002UKCL – Issue 9 (28 October 2003) Port Pinouts...

  • Page 64: Isdn Port - Pri (Rj45)

    Request to Send (RTS) Clear to Send (CTS) Data Set Ready (DSR) Signal Ground Data Carrier Detect (DCD) Data Terminal Ready (DTR) Ring Indicator (RI) Page 64 - Technical Data IP Office Installation Manual Port Pinouts 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 65: Audio Port (3.5Mm Stereo Jack Socket)

    Pin 1 and Pin 3, ensure that Pin 1 is at a positive voltage with respect to Pin 3. Each circuit can be switched independently. Switch Setting Information Low resistance between Pins. High resistance between Pins. IP Office Installation Manual Technical Data - Page 65 40DHB0002UKCL – Issue 9 (28 October 2003) Port Pinouts...

  • Page 66: Wan Port (37 Way D-Type Socket)

    X21: Pin 7 is connected to pin 6 V24/28: Pin 25 is connected to pin 6 V35: Pins 7 and 25 are connected to pin 6 Page 66 - Technical Data IP Office Installation Manual Port Pinouts 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 67: Cables

    RTS (Request To Send) CTS (Clear To Send) DSR (Data Set Ready) Ground DCD (Data Carrier Detect) DTR (Data Terminal Ready) RI (Ring Indicator) IP Office Installation Manual Technical Data - Page 67 40DHB0002UKCL – Issue 9 (28 October 2003) Cables...

  • Page 68: Dt Line Cord For Structured Cabling

    This cable can be used to replace the RJ11 to BT Newplan plug that is attached to the 20 series telephones to allow connection to structured cabling. Page 68 - Technical Data IP Office Installation Manual Cables 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 69: Pri/Bri Isdn Cable

    Twisted pair * With reference to the TE. Pins 7 and 8 are through connected for ease of construction. They are not actually used. IP Office Installation Manual Technical Data - Page 69 40DHB0002UKCL – Issue 9 (28 October 2003) Cables...

  • Page 70: Lan Interconnect Cable

    When connecting a WAN3 to an IP403/406 hub port which is located in the same cabinet as the IP Office. Pins 4,5,7 and 8 are through connected for ease of construction. They are not actually used. Page 70 - Technical Data IP Office Installation Manual Cables 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 71: Lan Cable

    IP Office. Pins 4, 5, 7 and 8 are through connected for ease of construction. They are not actually used. IP Office Installation Manual Technical Data - Page 71 40DHB0002UKCL – Issue 9 (28 October 2003) Cables...

  • Page 72: Lan Crossover Cable

    This cable is used when connecting Hub Ports 1 - 7 directly to another Hub and for connecting a WAN3 to an IP412. Page 72 - Technical Data IP Office Installation Manual Cables 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 73: Expansion Interconnect Cable

    White/Brown Twisted Pair Tx-B Brown/White The RJ45 Plug Shell at each end of the cable is connected to the STP Cable Drain Wire. IP Office Installation Manual Technical Data - Page 73 40DHB0002UKCL – Issue 9 (28 October 2003) Cables...

  • Page 74: V.24/V.28 Wan Cable

    The maximum core to core capacitance must not exceed 800pF. This cable is used to connect a WAN port to a Digital leased Line. Page 74 - Technical Data IP Office Installation Manual Cables 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 75: X.21 Wan Cable

    Pin 19 at end A is connected to the Screened Cable Drain Wire. This cable is used to connect a WAN port to a Digital leased Line. IP Office Installation Manual Technical Data - Page 75 40DHB0002UKCL – Issue 9 (28 October 2003) Cables...

  • Page 76: Wan Cable

    The maximum core to core capacitance must not exceed 800pF. This cable is used to connect a WAN port to a Digital leased Line. Page 76 - Technical Data IP Office Installation Manual Cables 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 77: Telephone Converter Cables

    BT Newplan socket connections may be reversed as polarity is not important. This adapter may be used with DT telephones fitted with BT Newplan plugs. IP Office Installation Manual Technical Data - Page 77 40DHB0002UKCL – Issue 9 (28 October 2003) Cables...

  • Page 78: Port Safety Classification

    Page 78 - Port Safety Classification Technical Data Port Safety Classification The Avaya IP Office systems have the following ports: • Expansion ports • 10/100 BaseT LAN ports • Telephone ports which are either DT (A-Law encoding) or DS (µ-Law encoding) •...

  • Page 79: Technical Specifications

    Control Maximum Voltage - 55V d.c. On state resistance - 0.7Ω. Short circuit current - 1A. Reverse circuit current capacity - 1.4A. IP Office Installation Manual Technical Data - Page 79 40DHB0002UKCL – Issue 9 (28 October 2003) Technical Specifications...

  • Page 80: Protocols

    Internal Data Channels Base Max. No. of Internal Data Channels Max. No. of Internal Data Channels for Unit Voicemail IP401 IP403 IP406 IP412 Page 80 - Technical Data IP Office Installation Manual Technical Specifications 40DHB0002UKCL – Issue 9 (28 October 2003)
  • Page 81 Technical Data Technical Specifications - Page 81 IP Office Installation Manual Technical Data - Page 81 40DHB0002UKCL – Issue 9 (28 October 2003) Technical Specifications...

  • Page 82: Snmp Functionality

    - Provides extension/user/phone-port map. • Phone-port mapping via cross-reference to entPhysicalEntry for port with entPhysicalIndex value - Provides notifications of phone change event. • IpoPhonesChangeEvent Page 82 - Technical Data IP Office Installation Manual Technical Specifications 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 83: Trap Generation

    SERVICES-MIB DIFFSERV-DSCP-TC.mib snmp_mibs\Standard on IP Office Admin CD DIFFSERV-MIB-HPOV.mib snmp_mibs\Standard on IP Office Admin CD IPO-PHONES-MIB.mib snmp_mibs\IPOffice on IP Office Admin CD IP Office Installation Manual Technical Data - Page 83 40DHB0002UKCL – Issue 9 (28 October 2003) Technical Specifications...

  • Page 84: Castlerock Snmpc 5.1.6C And Earlier

    STANDARD.mib file. Therefore to resolve the issue the required definition of zeroDotZero must be placed in the SNMPv2-SMI section in SNMPc's STANDARD.mib file. Page 84 - Technical Data IP Office Installation Manual Technical Specifications 40DHB0002UKCL – Issue 9 (28 October 2003)

  • Page 85: Index

    Trunk Modules.................................. 12 , 16 , 20 Unpacking ......................................38 UPS Equipment....................................34 USB Interface..................................... 8 , 12 Ventilation ......................................33 Voice over IP..................................7 , 11 , 15 IP Office Installation Manual Index - Page 85 40DHB0002UKCL – Issue 9 (28 October 2003)
  • Page 86 Avaya Inc. All other trademarks are the property of their respective owners. This document contains propriety information of Avaya and is not to be disclosed or used except in accordance with applicable agreements. Any comments or suggestions regarding this document should be sent to "wgctechpubs@avaya.com".
