H3C UniServer R4700 G6 Technology White Paper page 7

Item
(11) Riser card
(12) NVMe VROC module
(13) Power supply
(14) Rear drive backplane
(15) Storage controller
(16) Standard PCIe network
adapter
(17) Riser card blank
(18) OCP adapter
(19) Chassis
(20) GPU module
(21) Chassis ears
(22) Drive
(23) LCD smart management
module
(24) Drive backplane
(25) Air baffle
(26) Processor socket cover
(27) Processor heatsink
(28) Processor
(29) Processor retaining bracket
(30) Fan
(31) Serial & DSD module
(32) Server management
module
Description
Provides PCIe slots.
Works with Intel VMD to provide RAID capability for the server to
virtualize storage resources of NVMe drives.
Supplies power to the server. The power supplies support hot swapping
and 1+1 redundancy.
Provides power and data channels for drives at the server rear.
Provides RAID capability to SAS/SATA drives, including RAID
configuration and RAID scale-up. It supports online upgrade of the
controller firmware and remote configuration.
Installed in a standard PCIe slot to provide network ports.
Installed on an empty PCIe riser connector to ensure good ventilation.
Provides one slot for installing an OCP network adapter and two slots for
installing drives at the server rear.
N/A
Provides computing services such as graphics processing and AI.
Attach the server to the rack. The right ear is integrated with the front I/O
component, and the left ear is integrated with VGA connector, dedicated
management connector, and USB 3.0 connector.
Provides data storage space. Drives support hot swapping.
Displays basic server information, operating status, and fault
information. Together with HDM event logs, users can fast locate faulty
components and troubleshoot the server, ensuring server operation.
Provides power and data channels for drives.
Provides ventilation aisles for processor heatsinks and memory modules
and provides support for the supercapacitor.
Installed over an empty processor socket to protect pins in the socket.
Cools the processor.
Integrates memory and PCIe controllers to provide data processing
capabilities for the server.
Attaches a processor to the heatsink.
Helps server ventilation. Fans support hot swapping and N+1
redundancy.
Provides two SD card slots and forms RAID 1 by default.
Provides I/O connectors and HDM out-of-band management features.
6
