00.0; PER IO D = 12:00; CY CL E = 12:10; D EL AY STA RT = 00:00;
CY CL E G IV EN = 00:00; KV O M L /H R = 00.0; M L G IV EN = 000; R ES
V O L = O FF; M L /H R = 00.0; M ode = Interm ittent; and L ock L evel 0 or
L ock L evel 1 revert to L ock L evel 2. Call Custom er Service: 800-426-2448.

4.4.1 The Reservoir-Residual (RES VOL) Volume Alarm

If the pump is running, the RES VOL numeric value will decrease as the pump
delivers the drug until the counter has counted down to 5 ml. At that point, the
RES VOL numbers on the display will flash about every two seconds. When
RES VOL reaches 3 ml, you will hear a 3-second variable-tone alarm. At 2 ml
you will hear a 6-second variable-tone alarm, and at 1 ml you will hear a 9-
second variable-tone alarm. When RES VOL reaches 0 ml, all pumping action
ceases, and the pump will automatically enter the Stop mode. You will then hear
two short beeps every second until you press particular keys. When you press
either the STOP/START key or the SET/CLEAR key, the alarm will be shut off,
and the volume setting will return to its original programmed value.

4.4.2 The High Pressure (HI P) Alarm

You will hear a continuous, variable-tone alarm if the delivery pressure within
the fluid path becomes excessive. The letters "HI P" will appear on the display.
The high pressure alarm activates a switch at the base of the pump. If you find
the cause of the alarm and correct the problem, the alarm will stop automati-
cally. If you cannot find the cause, you can shut off the alarm by pressing the
STOP/START key. However, the letters "HI P" will remain on the display, and
you will hear the alarm again every 5 minutes. When you have corrected the
problem, the Stop mode display will replace the HI P display. You may then
start the pump again and resume delivery.
45
