Items Packaged With The Pump; Description Of The Function Keys And Display Panel - SIMS Deltec CADD-PLUS 5400 Operator's Manual

2.2.1

Items Packaged with the Pump

Packaged with the pump are the following items:
1 Battery (9-volt)
1 50 ml Medication Cassette
only)
1 Carrying case
1 Carrying pouch
1 Operator's Manual with warranty information
The following products are also compatible with the CADD-PLUS
• Medication Cassette
Extension Set with Anti-Siphon Valve
• CADD Administration Set with integrated or Add On Anti-Siphon Valve
®
• Pump Pouches
2.2.2

Description of the Function Keys and Display Panel

Liquid Crystal Display (LCD). This is the pump's display panel; the screen
which shows the pump's various functions or modes and the values you pro-
gram for them. In this manual, the term "display" is synonymous with display
panel or LCD.
STO P/START Key. Press and hold the STOP/START key to start or stop pump
delivery.
SET/CLEAR Key. Use the SET/CLEAR key for programming, setting or reset-
ting, and clearing of numbers in the computer's memory. You also use this key
for setting the Continuous or Intermittent mode.
PRIME Key. Use the PRIME key to fill the tubing and to remove air bubbles
from the fluid path.
LO CK Key. Use the LOCK key to lock out or limit the patient's operation of the
pump.
SELECT MO DE Key. Use the SELECT MODE key to view the various delivery
and programming modes, such as Continuous or Intermittent delivery and RES
VOL. When the pump is in the Stop or Start mode, and you press and release the
SELECT MODE key, the pump will display each mode in succession. You will
have to press the SELECT MODE key each time you wish to access another
mode. (See Section 3.9, "Reviewing the CADD-PLUS
SCRO LL Keys. Use the up or down SCROLL keys to increase or decrease the
numeric value shown on the pump's display.
™
Reservoir (nonsterile, for demonstration
™
Reservoir (50- or 100-ml), to be used with the
®
pump:
®
Programming Modes.")
5
