The AIE900A-AO is convenient for your various hardware configurations, such as SSD (Solid
State Drive), M.2 Key E module, M.2 Key B module, and PCI Express Mini Card modules.
Chapter 2 will show you how to install the hardware.
2.1
Installing the PCI Express Mini Card
Step 1 Turn off the system, and unplug the power adaptor.
Step 2 Flip the system upside down and loosen seven screws at the bottom
side, as marked with red circles in the figure below.
Step 3
Take off the bottom cover, and locate the PCI Express mini card slot on the
board.
Hardware Installation
AIE900A-AO Series User's Manual
HARDWARE INSTALLATION
SECTION 2
13
