- Page 1 维修手册 Service Manual, 2017 v1.0 维修手册 Service Manual 适用机型 Applicable Models NF15-18U （本图片为参考示意图，具体外观和配置以实物为准）(The picture is only for reference, and specific appearance and configuration are subject to the real product) 编制 冯占 Prepared by 审核 谭成波 Reviewed by 批准 杜文波 Approved by...
-
Page 2: Important Safety Notice
Midea Environment Appliance Technical Maintenance Manual Copyright @2017 All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written approval by the Overseas Sales of Midea Environment Appliance. 2 / 12... -
Page 3: Safety Warning Code
维修手册 Service Manual, 2017 v1.0 安全警示规范 Safety Warning Code WARNING Read these instructions. Keep these instructions. Follow all instructions. Do not use this appliance near water. This appliance is intended to be used in household and similar environments. Clean only with a damp cloth. Install in accordance with the manufacturer’s instructions. - Page 4 维修手册 Service Manual, 2017 v1.0 整机拆卸 Dismantling of appliance 装饰环拆卸 Dismantling of The decoration ring 机台后壳放平,底侧对人,拆除一颗螺钉后,按照 箭头指示依次拆除装饰环三个扣。 The rear shell of the machine is flat and the bottom side is on the side. After removing a screw, the three rings of the decorative ring are removed accordance with...
- Page 5 维修手册 Service Manual, 2017 v1.0 发热丝和顶盖拆卸 Dismantling of The Heating coil and the top cover 螺丝拆除两颗发热丝即可拆下;顶盖向外翻出 顶盖组件拆除. The Heating coil can be dismantled by removing two screws, and the top cover is removed from the top cover component. 按键组件拆卸 Dismantling of the Switch 拆除一颗螺丝,PCB 可以拆除.
- Page 6 维修手册 Service Manual, 2017 v1.0 用螺丝批松开固定电机的四颗螺钉,即可将发 热丝支架和电机一起拆除. Loosen the four screws which fixed on the motor by the screwdriver, the heater bracket and the motor could be remove together. 电源线拆卸 Disassembling of the power cord 从后壳取出电源线 Remove the power cord from the rear shell 6 / 12...
-
Page 7: Function And Operation
维修手册 Service Manual, 2017 v1.0 整机的安装 Function and operation 发热丝插线 Hot wire inserting line 将对于线束插入发热丝组件对应端子。 Inserting a wire harness into the corresponding terminal of the heating component 紧固电源线 Fastening power line and dump switch 将电源线穿过后壳对应孔位， 用钳子扭动档卡位置紧固。 The power line passes through the rear shell to correspond to the hole position, Fasten the position with the clamp. - Page 8 维修手册 Service Manual, 2017 v1.0 按键开关安装及插线 Knob switch installation and plug line 将按键板固定在顶盖上, 背面锁附一颗螺钉. Fix the Key board on the top cover and lock one screw on the back. 发热丝固定安装 Fixed installation of hot wire 将发热丝按图示方向固定在发热丝支架上,加 锁两颗螺丝. The heating wire is fixed on the heating wire bracket according to the direction of the picture, and two screws are locked.
- Page 9 维修手册 Service Manual, 2017 v1.0 线冒、扎带固定线束 Fixed wire harness 电机黑线插到发热丝对应端子上 Motor black to wire heating element 整理线束 Collate the harness 按图示整理 Arrange according to the diagram 紧固风叶 Fastening blade 风叶使用两只卡簧固定在电机 D 型轴顶端. The blades are fixed on the top of the D shaft by two clamping springs.
-
Page 10: Fault Code And Solutions
维修手册 Service Manual, 2017 v1.0 安装前壳格栅和装饰环 Installation of the front shell and decoration ring 前壳扣在后壳上，格栅扣在前壳上,锁附六颗 螺钉; 装饰环分清上下方向,扣紧前壳后,加锁一颗 螺钉. The front shell is buckled on the rear shell and the grid is buckled on the front shell. Then locks six screws. The decorative ring is divided into upper and lower directions, and a screw is locked after fastening the front shell. - Page 11 维修手册 Service Manual, 2017 v1.0 附录 Appendix: 整机接线图 Electrical Schematic Diagram 风扇维修常用工具、设备和材料 refrigerator maintenance tooling and equipment and material 工具 Tooling 名称 图片 主要用途 Name Photo Main Usage 十字螺丝刀 拆卸螺钉 Phillips screw assemble and screwdriver disassemble 11 / 12...
- Page 12 维修手册 Service Manual, 2017 v1.0 平口螺丝刀/小铲刀 拆卸螺钉和铆钉 screw and slotted screwdriver/scraper rivet assemble and disassemble 12 / 12...
