GD Midea Environment Appliances MFG.CO.,Ltd.
Midea Industrial Park, Dongfu Road, Dongfeng Town, Zhongshan, Guangdong,
528425, P.R.China
ELECTRIC FAN
OWNER'S MANUAL
12" Desk Fan
MODEL: FT30-8HC
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
Advertisement
Table of Contents
Related Manuals for Midea FT30-8HC
Summary of Contents for Midea FT30-8HC
- Page 1 ELECTRIC FAN OWNER’S MANUAL 12" Desk Fan MODEL: FT30-8HC READ AND SAVE THESE INSTRUCTIONS GD Midea Environment Appliances MFG.CO.,Ltd. Attention: Pictures in the IM are for reference only. Midea Industrial Park, Dongfu Road, Dongfeng Town, Zhongshan, Guangdong, 528425, P.R.China...
- Page 2 CAUTION Read Rules for Safe Operation and Instructions Carefully. WARNING 1. If the supply cord is damaged, it must be replaced by manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 2. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
- Page 3 PART FIGURE 1. Front grill 2. Blade 3. Plastic nut 4. Rear grill 5. Motor shaft 6. Oscillating clutch knob 7. Pedestal 8. Spinner 9. Base 10. Piano switch 11. Tight 12. Loose Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between the real object and the illustration in the drawing shall be subject to the real subject.
- Page 4 OPERATION INSTRUCTION Speed control: Speed is controlled by the piano switch. (-0 -1 -2 -3) 0-off 1-low 2-medium 3-high Oscillation control: To make the fan oscillate, push down on the oscillating clutch knob located on the top of the motor housing. To stop the fan down from oscillating in the position desired, push on the oscillating clutch knob once more.
