- Page 1 OWNER ’S & IN STALLATION MANUAL Fan Coil Unit Of Duct Type Thank you very much for purchasing our air conditioner, Before using your air conditioner, please read this manual carefully and keep it for future reference.
-
Page 3: Table Of Contents
Install according to this installation instructions strictly. CONTENTS PAGE If installation is defective, it will cause water leakage, electrical shock and fire. PRECAUTIONS..................1 When installing the unit in a small room, take measures INSTALLATION INFORMATION..............2 against to keep refrigerant concentration from exceeding FUNCTIONS &... -
Page 4: Installation Information
2. INSTALLATION INFORMATION CAUTION To install properly, please read this "Owner’s & Installation Before installing the unit,it is necessary to check manual" at first. whether the ground wire is charged. If it is,the unit shall not be installed before correction. The air conditioner must be installed by qualified persons. -
Page 5: Parts Names
Precautions before installation 6. PARTS NAMES Decide the correct way of conveying the equipment. The above figures is an instance models, which would be different from the one that you purchase. Try to transport this equipment with the original package. If the air conditioner needs to be installed on a metal part of the air return cabinet building, electric insulation must be performed, and the installation... - Page 6 Concrete iron Embedded bolt (With embedded Gasket bolt in pipe) Pendant Pendant bolt assembly Fig.7-6 Suspending the indoor unit Fig.7-4 Use tools such as pulleys to hoist the indoor unit to the pendant bolt. New concrete roughcast Use tools such as gradienter to settle the indoor unit Set it with embedded bushes or embedded bolts.
- Page 7 Four pipe type (unit:mm) The quantities of the fans and motors are only for reference, please prevail in kind! B (Air return port) Electric control box Hot water outlet RC3/4” Condensation water draining port 4-10X16Hoisting hole Cold water outlet RC3/4” Air release valve Condensation...
-
Page 8: Pipe Connection
8. PIPES CONNECTION Bend With air release valve, the other side is water inlet pipe. S-shape When connect water collecter, set the tightening torque to 6180~7540N.cm(630~770kgf.cm), and use a spanner to tighten it as shown in Figure. Fig.9-2 The diameter of connective junction in water inlet pipe and water outlet pipe is RC3/4 tapper pipe thread inside. -
Page 9: Wiring
10. WIRING CAUTION The air conditioner should use separate power supply with rated voltage. The external power supply to the air conditioner should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit. The wiring work should be done by qualified persons according to circuit drawing. An all-pole disconnection switch having a contact separation of at least 3mm in all poles should be connected in fixed wiring. - Page 10 10.1 Wiring Diagram OF F OF F SW1 SW2 C N3 LED 4 MAIN BOAD ALARM EARTH MOTOR1 MOTOR2 HI MID LOW YELLOW/GREEN POWER IN Ground wire Nuetral wire POWER IN Three-speed switch Live wire Owner’s & Installation manual...
- Page 11 10.2 The default model of DC fan coil is set as 12Pa when leaving the factory. Clients can dial to the responding position to choose the model and static pressure according to the nameplate and actual static pressure requirements of the models and static dial code table . Models and static dial code table : Static pres sure...
- Page 12 MODE:MKT2-V200 Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 1.68 Cooling capacity(latent) Prated,c 0.34 Heating capacity Prated,h 2.57 Total electric power input Pelec 0.018 Sound power level(per speed setting,if applicable) 52/42/33...
- Page 13 MODE:MKT2-V600 Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 4.07 Cooling capacity(latent) Prated,c 0.71 Heating capacity Prated,h 6.25 Total electric power input Pelec 0.053 Sound power level(per speed setting,if applicable) 58/51/42 contact details MODE:MKT2-V800 Information to identify the model(s)to w hich the information relation:...
- Page 14 MODE:MKT3-V200 Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 1.75 Cooling capacity(latent) Prated,c Heating capacity Prated,h 2.68 Total electric power input Pelec 0.017 Sound power level(per speed setting,if applicable) 50/40/33 contact details MODE:MKT3-V300 Information to identify the model(s)to w hich the information relation: Item...
- Page 15 MODE:MKT3-V600 Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 4.49 Cooling capacity(latent) Prated,c 1.36 Heating capacity Prated,h 6.62 Total electric power input Pelec 0.049 Sound power level(per speed setting,if applicable) 57/49/42 contact details MODE:MKT3-V800 Information to identify the model(s)to w hich the information relation:...
- Page 16 MODE:MKT4-V200 Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 1.71 Cooling capacity(latent) Prated,c 0.51 Heating capacity Prated,h 2.81 Total electric power input Pelec 0.017 Sound power level(per speed setting,if applicable) 50/41/33 contact details MODE:MKT4-V300 Information to identify the model(s)to w hich the information relation:...
- Page 17 MODE:MKT4-V600 Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 4.41 Cooling capacity(latent) Prated,c 1.46 Heating capacity Prated,h 6.47 Total electric power input Pelec 0.051 Sound power level(per speed setting,if applicable) 57/50/42 contact details MODE:MKT4-V800 Information to identify the model(s)to w hich the information relation:...
- Page 18 MODE:MKT3-V200F Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 1.374 Cooling capacity(latent) Prated,c 0.29 Heating capacity Prated,h 2.453 Total electric power input Pelec 0.017 Sound power level(per speed setting,if applicable) 51.1/41.1/38.7 contact details MODE:MKT3-V300F Information to identify the model(s)to w hich the information relation:...
- Page 19 MODE:MKT3-V600F Information to identify the model(s)to w hich the information relation: Item Symbol Value Unit Cooling capacity(sensible) Prated,c 3.601 Cooling capacity(latent) Prated,c 0.805 Heating capacity Prated,h 6.034 Total electric power input Pelec 0.05 Sound power level(per speed setting,if applicable) 59.1/52.2/43.7 contact details MODE:MKT3-V800F Information to identify the model(s)to w hich the information relation:...
- Page 20 16126200000003 V4.0...
- Page 21 此页不做印刷，仅做变更说明： 1、版本号由c改成d。 增加Lot21法规参数 版本号由D升级为E: 第2页增加“ Before installing the unit,it is necessary to check whether the ground wire is charged. ” If it is,the unit shall not be installed before correction. 第3页增加“ Before installing the unit,be sure to confirm with the user whether there are wires,water pipes,air pipes and so on in ”...
