wide AC input voltage range 176÷264V
•
high efficiency 85%
•
LED optical signalisation
•
1. Technical description.
1.1. General description.
The power supply unit is intended for the feeding of alarm system equipments, which require 12V DC supply
voltage and current load I=14A. The design enables simple changing of the output voltage, within the range of 12V÷15V
DC, using a potentiometer. The power supply unit is protected against short-circuit, overload and overvoltage.
1.2. Technical parameters.
Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple voltage
Short-circuit protection SCP
Overload protection OLP
Overvoltage protection OVP
Optical signalisation
Operation conditions
Dimensions (LxWxH)
Net/gross weight
Protection class PN-EN 60950-1:2007
Connectors
Electrical strength of insulation:
- between input (network) circuit and output
circuits of power-supply (I/PO/P)
- between input circuit and PE protection circuit
(I/P-FG)
- between output circuit and PE protection circuit
(O/P-FG)
Insulation resistance:
- between input circuit and output or protection
circuit
Storage temperature
Vibrations and impulse waves during transport
PS 12V/14A enclosed switch mode power supply
Features of the power supply unit:
<30°C
=40°C
PS20012140
Edition: 1 from 05.12.2011
Supercedes edition: ....................
protections:
•
•
•
•
•
176 ÷ 264 V AC 50÷60Hz
1,36A@230VAC max.
200W max.
85%
12V DC
14A
14A - see graph 1.
10A - see graph 1.
12 V ÷ 15V DC
100mV p-p max.
electronic, automatic recovery
105-150% of power supply, automatic recovery
U>115% ÷ 135% of the output, isolation
of the output voltage, automatic recovery
green LED – presence of DC voltage
2-nd enviromental class, temperature: -10
relative humidity 20%...90%, without condensation
226 x 115 x 50 [mm]
0,82kg / 0,90kg
I (first) – requires a protective conductor (PE)
power-supply:Φ0,63-2,50 (AWG 22-10)
outputs : Φ0,63-2,50 (AWG 22-10)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
100 M , 500V/DC
-20ºC...+60ºC
according to PN-83/T-42106
1
SCP short-circuit protection
overvoltage OVP
overvoltage protection (AC input)
overload (OLP)
o
o
C÷40
C
EN
Advertisement
Table of Contents
Related Manuals for Pulsar PS20012140
Summary of Contents for Pulsar PS20012140
- Page 1 PS20012140 PS 12V/14A enclosed switch mode power supply Edition: 1 from 05.12.2011 Supercedes edition: ……………….. Features of the power supply unit: wide AC input voltage range 176÷264V protections: • • high efficiency 85% SCP short-circuit protection • • LED optical signalisation overvoltage OVP •...
- Page 2 1.3. Output current vs temperature. Graph 1. Allowable output current from the power supply depending on ambient temperature. 2. Installation. 2.1. Requirements. The power supply shall be mounted by the qualified installer having appropriate (required and necessary for a given country) permissions and qualifications for connecting (operating) low-voltage installations. The unit shall be mounted in closed rooms, according to the environment class II, of the normal air humidity (RH=90% max.
- Page 3 2.4. Dimensions and fitting of the PS20012140 power supply. Fig. 2. Dimensions of power supply. 3. Maintenance. All maintenance procedures can be performed after the disconnection of the power supply from the electrical grid. The power supply does not require any special maintenance procedures, but in the case of significant dust accumulation,...
- Page 4 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the date of purchase placed on the purchase order. 2. Should such purchase order be missing when the claim is submitted, the three-year guarantee period is counted from the date of the manufacturing of the device.
