universal AC input voltage range 85÷264V
•
high efficiency 81%
•
LED optical signalisation
•
1. Technical description.
1.1. General description.
The power supply unit is intended for the feeding of alarm system equipments, which require 24V DC supply
voltage and current load I=2,5A. The design enables simple changing of the output voltage, within the range of 24V÷28V
DC, using a potentiometer. The power supply unit is protected against short-circuit, overload and overvoltage.
1.2.Technical parameters.
Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple voltage
Short-circuit protection SCP
Overload protection OLP
Overvoltage protection OVP
Optical signalisation
Operation conditions
Dimensions (LxWxH)
Net/gross weight
Protection class PN-EN 60950-1:2007
Connectors
Electrical strength of insulation:
- between input (network) circuit and output circuits of
power-supply (I/PO/P)
- between input circuit and PE protection circuit (I/P-
FG)
- between output circuit and PE protection circuit
(O/P-FG)
Insulation resistance:
- between input circuit and output or protection circuit
Storage temperature
Vibrations and impulse waves during transport
PS 24V/2,5A enclosed switch mode power supply
Features of the power supply unit:
<30°C
=40°C
PS602425
Edition: 1 from 05.12.2011
Supercedes edition: ............
protections:
•
SCP short-circuit protection
•
overvoltage OVP
•
overvoltage protection (AC input)
•
overload (OLP)
•
85 ÷ 264 V AC, 120 ÷ 370 V DC
0,6A@230VAC max.
60W max.
81%
24V DC
2,5A
2,5 A - see graph 1.
1,8 A - see graph 1.
24 V ÷ 28V DC
150mV p-p max.
electronic, automatic recovery
105-150% of power supply, automatic recovery
U>115% ÷ 135% of the output, isolation
of the output voltage, automatic recovery
green LED – presence of DC voltage
2-nd enviromental class, temperature: -10
relative humidity 20%...90%, without condensation
159 x 97 x 38 [mm]
0,48kg / 0,51kg
I (first) – requires a protective conductor (PE)
power-supply:Φ0,63-2,50 (AWG 22-10)
outputs : Φ0,63-2,50 (AWG 22-10)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
100 M , 500V/DC
-20ºC...+60ºC
according to PN-83/T-42106
1
EN
o
o
C÷40
C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pulsar PS602425
Summary of Contents for Pulsar PS602425
- Page 1 PS602425 PS 24V/2,5A enclosed switch mode power supply Edition: 1 from 05.12.2011 Supercedes edition: ………… Features of the power supply unit: universal AC input voltage range 85÷264V protections: • • high efficiency 81% SCP short-circuit protection • • LED optical signalisation overvoltage OVP •...
