Pulsar PS-2002470 Manual

Ps 24v/7a enclosed switch mode power supply

Advertisement

Quick Links

power output 7A/24÷28VDC
wide AC input voltage range 176÷264V
high efficiency 85%
LED optical signalisation

1. Technical description.

1.1. General description.

The power supply unit is intended for the feeding of alarm system equipments, which require 24V DC supply voltage
and current load I=7A. The design enables simple changing of the output voltage, within the range of 24V÷28V DC, using a
potentiometer. The power supply unit is protected against short-circuit, overload and overvoltage.

1.2. Technical parameters.

Supply voltage
Current consumption
Supply power
Efficiency
Output voltage
Output current t
AMB
Output current t
AMB
Voltage adjustment range
Ripple voltage
Short-circuit protection SCP
Overload protection OLP
Surge protection
Overvoltage protection OVP
Optical signalisation
Operation conditions
Dimensions (LxWxH)
Net/gross weight
Protection class PN-EN 60950-1:2007
Connectors
Electrical strength of insulation:
- between input (network) circuit and output
circuits of power-supply (I/PO/P)
- between input circuit and PE protection circuit
(I/P-FG)
- between output circuit and PE protection circuit
(O/P-FG)
Insulation resistance:
- between input circuit and output or protection
circuit
Storage temperature
Vibrations and impulse waves during transport
* In order to extend the life of the power supply, the load current of 5A is recommended.
*
See graph 1
PS 24V/7A enclosed switch mode power supply
Features of the power supply unit:
*
<30° C
=40° C
PS-2002470
Edition: 5 from 27.05.2014
Supersedes edition: 4 from 07.03.2013
protections:
warranty – 2 year from the production date
176 ÷ 264 V AC 50÷60Hz
1,36A@230VAC max.
200W max.
85%
24V DC
7A - see graph 1.
5A - see graph 1.
24 V ÷ 28V DC
150mV p-p max.
electronic, automatic recovery
105-150% of power supply, automatic recovery
varistors
>32V (automatic return)
green LED – presence of DC voltage
2-nd enviromental class, temperature: -10
relative humidity 20%...90%, without condensation
226 x 115 x 50 [mm]
0,82kg / 0,90kg
I (first) – requires a protective conductor (PE)
power-supply:Φ0,63-2,50 (AWG 22-10)
outputs: Φ0,63-2,50 (AWG 22-10)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
100 MΩ, 500V/DC
-20ºC...+60ºC
according to PN-83/T-42106
1
SCP short-circuit protection
overvoltage OVP
overvoltage protection
overload (OLP)
o
o
C÷40
C
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-2002470 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar PS-2002470

  • Page 1 PS-2002470 PS 24V/7A enclosed switch mode power supply Edition: 5 from 27.05.2014 Supersedes edition: 4 from 07.03.2013 Features of the power supply unit: • • protections: power output 7A/24÷28VDC • • SCP short-circuit protection wide AC input voltage range 176÷264V •...
  • Page 2 1.3. Output current vs temperature. Graph 1. Allowable output current from the power supply depending on ambient temperature (instantaneous load). 2. Installation. 2.1. Requirements. The power supply shall be mounted by the qualified installer having appropriate (required and necessary for a given country) permissions and qualifications for connecting (operating) low-voltage installations.
  • Page 3 2.4. Dimensions and fitting of the PS-2002470 power supply. Fig. 2. Dimensions of power supply. 3. Maintenance. All maintenance procedures can be performed after the disconnection of the power supply from the electrical grid. The power supply does not require any special maintenance procedures, but in the case of significant dust accumulation,...
  • Page 4 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, , counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such...
