Operating Instructions

Installation
• Take the product out of the packaging box.
• Place the heater on a flat surface as shown in picture 1.
Function Button Instructions
1. On/Off Button
1.1 Connect and turn on electricity, the heater enters standby mode. All indicator lights are off.
1.2 Under standby mode, press the
heater is turned on:
a) Body sensor mode indicator light is off, heater enters continuous mode.
b) PTC heating element starts working.
c) DC Fan turns on.
During operation, press
element stops working immediately, DC fan stops working after 10 seconds).
2. Body Sensor Button
2.1 When the device is on, press
2.2 Continuous mode: when turns off body sensor mode, the heater enters continuous mode. The heater
continuously works; PTC heating element and DC fan also work simultaneously.
2.3 Body sensor mode: When this mode is on, body sensor mode operates.
• Upon switching to the body sensor mode, the PTC heating element keeps operating for the first
2 minutes and the system will continuously detect the presence of human body; if human body is
detected within 2 minutes, it keeps functioning while resetting the timer for another 2-minute
interval. If human body is not detected, the PTC heating element will stop working after 2 minutes.
10 seconds later the motor will be switched off and stop generating warm air.
• Body sensor mode indicator: the sensor will be on as long as the PTC heating element and fan are
working. When human body is absent, they will be switched off and the indicator will keep flashing
at 1 Hz.
Note:
The machine has no memory function. Every time the heater reboots, by default the PTC heating
element is on and the body sensor function is off.
button once to turn on the device. The default setting after the
button once to turn off the heater (all indicator lights are off, PTC heating
button to turn on/off body sensor mode.
Figure 1
