© 2009, Videolarm, Inc. All Rights Reserved
M R 7 T
Indoor Dome Housings
Installation and Operation Instructions for the following models:
MR7T 7" Recessed Ceiling mount dome housing, tinted dome, plus (1) xed
camera bracket and decorative trim ring
MR7TL7" Recessed Ceiling mount dome housing, tinted dome, plus (1) xed
camera bracket and decorative trim ring, includes liner; MCL 8"
MR7CL7" Recessed Ceiling mount dome housing, clear dome, plus (1) xed
camera bracket and decorative trim ring, includes liner; MCL 8"
Before attempting to connect or operate this product,
please read these instructions completely.
© 2009, Videolarm, Inc. All Rights Reserved
www.videolarm.com
CERTIFIED
81-IN5139
01-09-2009
Advertisement
Table of Contents
Related Manuals for Moog Videolarm MR7T 7
Summary of Contents for Moog Videolarm MR7T 7
- Page 1 Indoor Dome Housings www.videolarm.com Installation and Operation Instructions for the following models: MR7T 7” Recessed Ceiling mount dome housing, tinted dome, plus (1) xed camera bracket and decorative trim ring MR7TL7” Recessed Ceiling mount dome housing, tinted dome, plus (1) xed camera bracket and decorative trim ring, includes liner;...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE Do not block any of the ventilation openings. -
Page 3: Limited Warranty
LIMITEDWARRANTY FOR VIDEOLARM INC. PRODUCTS VIDEOLARMINC. warrantsthis Productto be free from defectsin materialor workmanship,as follows: PRODUCTCATEGORY PARTS LABOR All Enclosures and Electronics Five (5) Years Five (5) Years Pan/Tilts Three (3) Years **6 months if used in autoscan Three (3) Years **6 months if used in autoscan /tour operation /tour operation Poles/PoleEvators... -
Page 4: Electrical Specifications
Electrical Specifications Content of Box MR7T No power options provided. Power required for camera only. Power 24VAC Class 2 Power Supply Only English Tools Required: Phillips Head Screwdriver Ceiling Support Wires(18-24 Gauge Wire) Ningunas opciones de la energía proporcionaron. Energía requerida para la cámara fotográfica solamente. - Page 5 11.125” Using the provided template, mark the A box cutter or jigsaw can be used for ceiling tile for the cutout. cutting the circle. • Un cortador o un rompecabezas de la caja se • Con la plantilla proporcionada, cortar el azulejo del techo puede utilizar para cortar el círculo.
- Page 6 Support Arms Rotate Support Arms Rotate Mounting Holes Support Arm Holes With the bottom flange pressed against the ceiling, Run electrical cable into the housing rotate support arms to the outside. Tighten the support through the conduit. arm screws. • Con el fondo el reborde presionó...
-
Page 7: Replacement Parts List
Reattach the trim ring/ dome assembly by pressing in and sliding (3) springs in the housing. • Reate el montaje de la bóveda del anillo del ajuste clavando y resbalando (3) los resortes en la cubierta. • Rattachez le dôme d'anneau d'équilibre en enfonçant et diapositive (3) des ressorts dans le logement. •... -
Page 8: Product Registration/Warranty
Product Registration/Warranty Thank you for choosing Videolarm. We value your patronage and are solely committed to providing you with only the highest quality products available with unmatched customer service levels that are second-to-none in the security industry. Should a problem arise, rest assure that Videolarm stands behind its products by offering some of the most impressive warranty plans available: 3 Years on all Housings, Poles, Power Supplies, and Accessories and 5 Years on all camera systems (SView, QView, Warriors), and InfraRed Illuminators.
