- Page 1 WWW.GVISION-USA.COM VW55CD-OM-40003 USER’S MANUAL 3.5MM BEZEL / 55-INCH VIDEO WALL MONITOR GVISION USA, INC 30398 Esperanza, Rancho Santa Margarita CA 92688 / 949.586.3338 / info@gvision-usa.com...
- Page 2 CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with this equipment, please contact GVISION. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located.
- Page 3 Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 4: Table Of Contents
Power Board……………………………………………………………………………………………………………..22 4.1 Isolation……………………………………………………………………………………………………………25 4.2 Safety……………………………………………………………………………………………………………….25 4.3 EMC……………………………………………………………………………………………………………..….25 4.4 Environmental Requirement…………………………………………………………………………………...26 4.5 Dimension…………………………………………………………………………………………………………26 4.6 Weight……………………………………………………………………………………………………………...26 4.7 Pin Connection…………………………………………………………………………………………………...27 4.8 Power Supply Mounting………………………………………………………………………………………...28 Specification…………………………………………………………………………………………………………..29 Mechanical Drawing………………………………………………………………………………………………….30 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 5: Controllers & Settings
DisplayPort (DP) Output Source USB IN Software Update RS232 IN Control the Screen via RS232 Protocol Input RS232 OUT Control the Screen via RS232 Protocol Output 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 6: Remote Control
Down: Press to move down Enter: Press to enter Exit: Press to exit the menu 1.2.1 IR Receiver Plug the IR receiver in the RS232 (RJ45 Shape) port. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 7: Software Address Setting
Figure 1.1 Press UP/DOWN to move and select VIDEO WALL icon, press ENTER. (Figure 1.2) Press ENTER again to set the ID. Figure 1.2 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 8 The [Row End] item and [Column End] item represent the software address of the bottom-right screen in the wall matrix. Figure 1.4 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
- Page 9 Column End 3 Row Total 3 Column Total 3 Move to [Video Wall Enable], select [On] to start splicing, select [Off] to display independently. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 10: Color Balance Adjustment
It is recommended to use the host computer for debugging work, which is convenient and quick to operate. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 11 Then adjust the parameters in "Image Adjustment". Please do not do any operation on the backlight brightness. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 12: Adjustment
It is necessary to increase the brightness value to make the screen white as much Figure 2.1 as possible, Adjust the value within 10 unit values. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 13 Note: Changing the "Blue Gain" has a great impact on the brightness of the picture, try to minimize the changes to the "Blue Gain" 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
- Page 14 Note: Reducing the saturation will result in a lighter color, so the one with the closest visual effect is the best. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 15: Driver Board
Multi-CANBUS parallel processing, powerful processing capability. Work 24/7. Support remote control to operate all splicing functions. No risk of virus infection, good safety. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 16: Driver-Board Overview
RS232 Input 16 (CN36) Backlight Connector 8 (CN32) 2 Χ RS232 Output 17 (CN39) Screen Cable Connector 9 (J12) External RTC (CN37) Internal HDMI Input 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 17: Main-Board Description
WWW.GVISION-USA.COM 3.3 Main-Board Description 3.3.1 PCB Dimension PCB Dimension: 1.6mm (H) x 201mm (L) x 122mm (W) 3.3.2 Mechanical Dimension 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 18: I/O Description
Red LED Light K8 Key Ground IR-IN Infrared Reception 5VDC Power J3 (4Pin/2.0mm): UART Connector SYMBOL DESCRIPTION 3.3V 3.3V Stand-by Power Ground Reception Transmission 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 19 12V Controlled DC Power Supply CN36 (6Pin/2.0mm): Backlight Connector SYMBOL DESCRIPTION Ground Ground Brightness Adjustment Backlight On/Off Pin 12V DC Power Output 12V DC Power Output 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
- Page 20 Clock Channel 0C- Clock Channel 0C+ Data Channel 02- Data Channel 02+ Data Channel 01- Data Channel 01+ Data Channel 00- Data Channel 00+ Ground Ground 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 21: Performing Index
Use the program upgrade function in host computer for USB upgrade Upgrade by selecting the firmware update (FW Update A) option in the menu 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 22: Power Board
Use a 0.1uF ceramic capacitor in parallel with a 10uF electrolytic capacitor at output connector terminals for Ripple & Noise measurements. Ripple & Noise test condition: Input voltage range is 100Vac～200Vac at rated current load. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 23 Note: The rise time measured from when the output voltage rises from 10% to 90% of specified output voltage Vout observed on the channel waveform. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
- Page 24 When Ps-on is pulled to TTL-low or open circuit, the DC outputs should be disabled. Ps-on Signal Comments Outputs Ps-on-high ≥ 2.5V&2.0mA (Source) Output Ps-on-low ≤ 0.5V Ps-on-open 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 25: Isolation
Radiated Emission: Emission: GB13837 GB13837 FCC PART13 FCC PART13 Note: The power board should be assembled in product to test for passing above criterion. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 26: Environmental Requirement
Z axis. Shock: 49m/s2 (5G), 11ms, once each X, Y and Z axis. Dimension 260(L) × 130(W) × 26(H)mm Weight 500g 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 27: Pin Connection
Table.18 Pin-CON4 connection & function Pin Connection Function 3, 4 SGND +24VDC RETURN 1, 2 +24V +24VDC OUTPUT Note: CON4--XH CONNECTION, TYPE: pitch 2.5mm. 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... -
Page 28: Power Supply Mounting
Note: The image shown here is indicative only. If there is inconsistency between the image and the actual product, the actual product shall govern. Power Supply Mounting 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 29 40N-60N. The insertion depth of the screw should SPS UNIT be less 5.5mm. Add 260(L)×130(W)×0.43(H)mm Mylar under PCB bottom. BOTTOM NATURAL WIND 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
-
Page 30: Specification
AC 100V ~ 240V, 50/60Hz TEMPERATURE Operating 0~50°C VESA™ Mount Size (mm) 400 x400 / 600 x 400 Specifications subject to change without any notice 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com... - Page 31 WWW.GVISION-USA.COM Mechanical Dimension VW55CD-OM-40003 30398 Esperanza Rancho Santa Margarita CA 92688 / Tel. 949-586-3338 / Fax. 949-272-4594 / Email. info@gvision-usa.com...
