GVision P15PX-L Specifications

1 5 " T F T L C D M o n i t o r
Advertising Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Audio System
USB HUB
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions ( W x H x D )
Carton Dimensions
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
Front Side
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
P15PX-LW
15" TFT active matrix panel
0.297(H) x 0.297 (V) mm
XGA 1024 x 768
400:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
304.1(H) x 228.1(V)
120 (H) x 100 (V)
CCFL x 2
40,000(hr)
o o
Tilt down: -5 , Tilt up: +15
Analogue VGA, Composite video
(NTSC/PAL)
D-sub 15 pin (VGA)
N/A
RCA, S-Video
H. scan 31~60KHz,
V. scan 60 ~ 75Hz
1W/per channel driver
N/A
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
AC Input,
Universal 100 ~ 240V
36W
VESA DPMS standard
390 x 406 x 195 mm
452 x 480 x 261 mm
5.3 Kg
C-UL, FCC, CE
Mechanical drawing
P15PX-L P15PX-J
P15PX-LW P15PX LW P15PX-LW
Features : F t
* High contrast color TFT LCD display supports
resolution up to XGA 1024x768. Compatible with IBM
VGA, VESA standards.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Multi signals: VGA, Composite video, S-video (Auto
detection of input signals.)
* Composite video system PAL/NTSC and SECAM
compatible.
* Built-in audio system.
* Optional stable photo frame stand base.
* Optional black & white housing.
* Optional VESA mounting.
Optional Accessories :
* Anti-Glare tempered glass.
* Photo stand
Ordering Information :
* P15PX-LW VGA + Video-in
* P15PX-JW VGA + Video-in + photo stand
I/O Ports
Audio in VGA S-Video RCA AC-in
Front Side Back Side
