Page 1: Operation Guide
Operation Guide 17” TFT LCD Monitor On Screen Display Control 1280 x 1024 Max. Resolution Video-in/Touch Screen Function... - Page 2 Key Control / Indicator Connector R0062131...
- Page 3 Package Contents Included with your LCD monitor are following items: 17” TFT liquid crystal monitor D-sub 15 pin signal cable DVI 24 pin signal cable ( option) Power apdater 12V/4A AC power cable DC 24V-in cable ( option ) Operation guide...
-
Page 4: Display Modes
Video in(RCA) This can be connected with the video-in RCA connector. Adjusting with the OSD Control To Display and Select the OSD Functions: Pressing ▲, ▼, , or once pops up the OSD function main menu. Pressing ▲ or ▼ a second time to select the different OSD control. Pressing button changes the value of the selected OSD control option. -
Page 5: Specifications
1280X960 VESA 60.0 60.0 + / + 1280X1024 VESA 64.3 60.0 + / + 1280X1024 VESA 80.0 75.0 + / + Specifications Model W7TH / S7TH LCD Display 17.0” TFT Active Matrix Panel Display Size 337.9(H) x 270.3(V) mm Pixel Pitch 0.264(H) x 0.264(V) mm Max. - Page 6 Federal Communication Commission Radio Frequency International Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
