GVision P17PH-L Specifications

1 7 " T F T L C D M o n i t o r 1 7 " T F T L C D M o n i t o r
POS Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal Connector Analog
Digital
Scan Frequency
Audio System
USB HUB
Touch Panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions ( W x H x D )
Carton Dimensions
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
P17PH-LA
17" TFT active matrix panel
0.264(H) x 0.264 (V) mm
SXGA 1280 x 1024
450:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
337.9(H) x 270.3(V)
140 (H) x 140 (V)
CCFL x 4
40,000(hr)
o o
Tilt down: -3 , Tilt up: +15
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (option)
H. scan 31~80KHz,
V. scan 56~75Hz
1W/per channel driver
N/A
Resistive/Capacitive - RS232
or USB A type (Option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Universal power adaptor
Input AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48W
VESA DPMS standard
439 x 461 x 195 mm
530 x 528 x250 mm
6.8kg
C-UL, FCC, CE
Mechanical drawing
P17PH-L P17PH-J
P17PH-LA P17PH LA P17PH-LA
Features :
* High contrast color TFT LCD display supports
resolution up to XGA 1280x1024. Compatible with IBM
VGA, VESA standards.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Built-in audio system.
* Optional stable photo stand excellent for touch solution.
* Optional black & white housing.
* Optional touch solutions.
* Optional VESA mounting.
* Hot key for AUTO adjustment.
Optional Accessories :
* 3M 5 Wire resistive touch panel
* 3M Capacitive touch panel
* ELO 5 Wire resistive touch panel
* Anti-Glare tempered glass
* Customized touch solutions acceptable
* Photo stand
Ordering Information :
* P17PH-LA VGA only
* P17PH-LB VGA + DVI
* P17PH-JA VGA + photo stand
* P17PH-JB VGA + DVI + photo stand
I/O Ports
Touch DC in DVI-D VGA Audio in
