GVision K17PH-F Specifications

1 7 " T F T L C D M o n i t o r
Industrial Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration g
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio*
Brightness*
Response Time* ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Speakers
USB HUB
Touch panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions (WxHxD)
Dimensions (Carton 2 in 1)
Weight (Net)
Certification
* Specifications are subject to change without notice.
I/O Ports
UNOT : mm
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
K17PH-FA
17" TFT active matrix panel
0.264(H) x 0.264 (V) mm
SXGA 1280 x 1024
450:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
337.9(H) x 270.3(V)
140 (H) x 140 (V)
CCFL x 4
40,000(hr)
Analogue VGA
D-sub 15 pin (VGA)
N/A
RCA, S-video (option)
H. scan 31 ~ 80KHz,
V. scan 56 ~ 75Hz
N/A
N/A
Resistive/Capacitive - RS232 or
USB A type (option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
0 C-50 C (32 F-122 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C (-4 F-140 F)
10%-90% (no condensation)
Input AC 100~240V , 50~60HZ
Output DC 12V/4A
48W
VESA DPMS Standard
449 x354 x 73 mm
530x528x250 mm
6.3 Kg
C-UL, FCC, CE
Mechanical drawing
VGA S-Video RCA
K17PH-FA K17PH FA K17PH FA
Features :
* High contrast color TFT LCD open frame display support
resolution up to SXGA 1280x 1024. Compatible with IBM
VGA, VESA standards.
* Flexible mechanical designs for industrial application.
* Multi-signals: VGA, Composite video,
s-video (Auto detection of input signals).
* Composite video system PAL/NTSC and SECAM
compatible.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Optional touch solutions.
Optional Accessories :
* 3M 5 Wire resistive touch panel
* 3M Capacitive touch panel
* ELO 5 Wire resistive touch panel
* Anti-Glare tempered glass
* Customized touch solution acceptable.
Ordering Information :
* K17PH-FA VGA only
* K17PH-FW VGA + Video-in
Touch
