GVision L20AU-G Specifications

UXGA 2 Mega-pixels
W h e r e V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signal
Signal connector Analog
Digital
Video-in
Scan Frequency
Audio System
USB HUB
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Dimensions Landscape
(WxHxD) Portrait
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNiT : mm
Front Side
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
y M e e t s F l e x i b i l i t y
L20AU-GE
20.1" TFT active matrix panel
0.255(H) x 0.255 (V) mm
UXGA 1600 x 1200
700:1 (Typical )
2
250 Cd/m (Typical )
25 ms
16,777,216 colors
408.0(H) x 306.0(V)
170 (H) x 170 (V)
6 CCFLs
50,000 hrs (typ.)
o
Height +/- 9cm, Swivel +/- 65 ,
o o o
Tilt 5 ~65 , Rotate +/- 90
Analogue VGA, Digital,
Composite Video
D-sub 15 pin (VGA)
DVI-D
Composite Video, S-video,
R/L RCA jack, (Option)
56/60/70/72/75 Hz
2.5W / per channel driver
USB 2.0
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Imbedded AC Input, Universal
100~240V, 50~60Hz
70 watts
481.95 x 449.97-539.97 x 209.98
377.95 x 539.97 x 209.99
17 Kg
CE, FCC, UL,TUV
Mechanical drawing
Back Side
L20AU GE L20AU GE
y
Features :
* 2 Megapixel format (1600 X 1200, UXGA).
* 20.1 Inch Diagonal Viewing Size.
* MVA /IPS wide view angle TFT LCD technology.
* Built In 90~264 Vac medical grade Power Supply.
* Height, swivel, Tilt, and Rotation adjustable Stand.
* Anti-Reflection Protective Contract Glass (Optional).
* Multi-Signal Inprts : VGA. DVI, Composite Video,
S-Video (Auto DetectionOF Input Signals).
* NTSC/PAL,Video Systmes compatible.
* Support DDC1/2B for Plug & Play Compatibility.
Optional Accessories :
* Anti-Glare Tempered Protection glass.
* USB 2.0 HUB.
* 2.5 Watts internal Speakers.
Ordering Information :
* L20AU-GB VGA, DVI-D
* L20AU-GE VGA, DVI-D, Video, S-Video, Audio
I/O Ports
DC in D-sub DVI Audio in S-Video Cubs Audio Speaker out
Front Side
AU
Back Side
