GVision P17BH-AA Specifications

1 7 " T F T L C D M o n i t o r 1 7 " T F T L C D M o n i t o r
POS Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio*
Brightness*
Response Time* ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal connector Analog
Digital
Scan Frequency
Audio Systems
USB HUB
Touch Panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions(WxHxD)
Carton Dimensions
Weight (Net)
Certification
* Specifications are subject to change without notice.
90
o
-5
o
30
Support Angle Asjstment -50
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s
P17BH-AA
17" TFT active matrix panel
0.264(H) x 0.264 (V) mm
SXGA 1280 x 1024
450:1 (typical)
2
250 Cd/m (typical)
16 ms (typical)
16M
337.9(H) x 270.3(V)
140 (H) x 140 (V)
CCFL x 4
40,000(hr)
o
Tilt down: -5 , Tilt up: +90
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (option)
H. scan 31~80KHz,
V. scan 56 ~ 75Hz
1W/per channel driver (option)
A type x 2, B type x 1 (option)
Resistive/Capacitive - RS232
or USB A type (Option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Imbedded AC Input,
Universal 100 ~ 240V
48W
VESA DPMS standard
392 x 382 x 180 mm
455 x 456 x 228 mm
TBD
C-UL, FCC, CE
Mechanical drawing
UNOT : mm
o
0 0
~+90
F l e x i b i l i t y F l e x i b i l i t y
Features :
* Fashionable housing design with slim bezel.
* High contrast color TFT LCD open frame display support
resolution up to XGA 1280x1024. Compatible with IBM
VGA, VESA standards.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Stable aluminum stand base supports angle adjustment
0 0
5 ~ +90
* Optional USB hub with 2 downstream ports and 1
upstream port.
o
* Optional touch solutions.
* Optional cable management function.
* Optional VESA mounting.
* Built in power.
* Hot key for AUTO adjustment.
Optional Accessories :
* 3M 5 Wire resistive touch panel
* 3M Capacitive touch panel
* ELO 5 Wire resistive touch panel
* Anti-Glare tempered glass.
* USB HUB
* Speakers
* Customized touch solutions acceptable.
Ordering Information :
* PA17H-AA
* PA17H-AB
I/O Ports
Front Side
P17BH AA P17BH-AA P17BH AA P17BH-AA
VGA only
VGA + DVI
USB HUB
Back Side
