Assembling the Soft Serve Ice Cream Maker

N.B: The bowl will begin to defrost rapidly after being removed from
the freezer. Have your recipe prepared before assembling the ice cream
maker, to ensure perfect results.
1. Remove the freezer bowl from
the freezer. Place the freezer
bowl into the main housing of
the ice cream maker. Locate and
align the mixing paddle into the
hole, on the underside of the lid.
Align and push into place until it
clicks and locks into place.
2. Slide the topping containers into the indent on the side of the ice
cream maker, so they are firmly in place. Place the lids over the top.
Note: The topping containers with the rounded edges should be
inserted into the side spaces.
3. Attach the dispensing arm with
the handle. Place the dispensing
arm, so that it sits right
underneath the product, but at
a 45-degree angle, to the front
of the unit. Align the hole in the
unit, with the dispensing hole in
the handle and turn clockwise
towards you, until the handle is
in position.
4. Slide the toppings chute into
the space provided, underneath
the topping containers. Be sure
to slide it all the way in, until it
stops.
