Sensor Instructions
Key fob Press and hold the Lock and Unlock buttons
simultaneously for 3 seconds.
Simon XT talking For sensor testing a 1.0. touch screen, press and hold
a
touch screen the Emergency icon for 5 seconds.
For sensor testing a 1.1 or greater touch screen, press
the Settings (gear) icon, scroll down, and then press the
RF Test icon.
a. Not investigated for use by UL.
Note: Refer to specific sensor installation instructions for complete operation and
testing details.

Sensor testing notes

•
Conduct sensor test in all possible environmental conditions (for example:
interior doors open and closed, HVAC system on and off, wireless music
system turned on and off).
•
Conduct sensor test whenever changes are made to the installation
environment that may impact RF performance (for example: mirrors installed,
metal backed wall paper, addition of other RF equipment).
• If a sensor doesn't meet minimum packet requirements, contact your installer.

Comm test

The comm test is used to check proper communication.
Note: If Comm Test is not finished, it will continue to run even if you exit program
mode.
To perform a comm test:
1. Enter the Status & Settings menu.
2. Scroll until System Tests is listed, Press Enter.
3. Enter your master code and press OK.
4. Press Comm Test.
The panel displays if the comm test was successful or not.
Simon XTi-5 User Manual
Minimum
packets
required
6 of 8
6 of 8
