Endress+Hauser Proline Promass A 300 PROFINET Operating Instructions Manual page 249

Proline Promass A 300 PROFINET
Sanitary compatibility
Pharmaceutical
compatibility
Certification PROFINET
Radio approval
Additional certification
Endress+Hauser
• 3-A approval
• Only measuring devices with the order code for "Additional approval", option LP "3A"
have 3-A approval.
• The 3-A approval refers to the measuring device.
• When installing the measuring device, ensure that no liquid can accumulate on the
outside of the measuring device.
Remote transmitters must be installed in accordance with the 3-A Standard.
• Accessories (e.g. heating jacket, weather protection cover, wall holder unit) must be
installed in accordance with the 3-A Standard.
Each accessory can be cleaned. Disassembly may be necessary under certain
circumstances.
• EHEDG-tested
Only devices with the order code for "Additional approval", option LT "EHEDG" have been
tested and meet the requirements of the EHEDG.
To meet the requirements for EHEDG certification, the device must be used with process
connections in accordance with the EHEDG position paper entitled "Easy Cleanable Pipe
Couplings and Process Connections" (www.ehedg.org).
• FDA
• Food Contact Materials Regulation (EC) 1935/2004
• FDA
• USP Class VI
• TSE/BSE Certificate of Suitability
PROFINET interface
The measuring device is certified and registered by the PNO (PROFIBUS User
Organization). The measuring system meets all the requirements of the following
specifications:
• Certified according to:
• Test specification for PROFINET devices
• PROFINET Security Level 2 – Netload Class
• The device can also be operated with certified devices of other manufacturers
(interoperability)
• The device supports PROFINET S2 system redundancy.
The measuring device has radio approval.
For detailed information regarding radio approval, see Special Documentation
→  253
CRN approval
Some device versions have CRN approval. A CRN-approved process connection with a CSA
approval must be ordered for a CRN-approved device.
Tests and certificates
• EN10204-3.1 material certificate, parts and sensor housing in contact with medium
• Pressure testing, internal procedure, inspection certificate
• PMI test (XRF), internal procedure, wetted parts, test report
• EN10204-2.1 confirmation of compliance with the order and EN10204-2.2 test report
Technical data
249
