Summary of Contents for thomann Millenium R1
- Page 1 R1 12" Metronome Practice Pad Drum Pad...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 11.09.2023, ID: 400714 (V2)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Connections and controls........................10 Device functions............................12 Operating the device..........................14 Technical specifications........................15 Plug and connection assignment....................16 Cleaning............................... 18 Protecting the environment...................... - Page 4 R1 12" Metronome Practice Pad Drum Pad...
-
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. - Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use Mobile Drums are used to convert digital trigger signals from drum pads into various drum sounds. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or prop‐ erty damage. - Page 8 Safety instructions WARNING! Incorrect handling of lithium batteries can result in injury! In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Handle lithium bat‐ teries in a correct and professional manner. Store lithium batteries in a cool and dry place in their original packaging. Keep lithium batteries away from sources of heat.
-
Page 9: Features
Features Features Built-in metronome (30…250 bpm, all note values) Headphones output (3.5 mm stereo jack socket) Display Beat counter (10…60 seconds) Adjustable rhythm (1…8 counting units) Speakers USB-C charge socket USB cable (included) R1 12" Metronome Practice Pad Drum Pad... -
Page 10: Connections And Controls
Connections and controls Connections and controls ö PHONES O/► ▌/TAP TRAIN VOLUME R1 12" Metronome Practice Pad Drum Pad... - Page 11 Connections and controls 1 Six-digit display 2 Rhythm display | Shows the current rhythm figure. 3 Multi-function button | Adjusts the beat, tempo, rhythm, sound and volume 4 Speakers 5 Strike area 6 [VOLUME] | Button for setting the overall volume of the practise pad 7 [SET] | Button for specifying the settings.
-
Page 12: Device Functions
Device functions Device functions ► ] for several seconds. Switching on To switch on the device, press the main switch [O/ The configuration menu now appears on the display. Use [SET] and turn the multifunction knob to can adjust the settings for ‘BEAT’ , ‘TEMPO’ , ‘RHYTHM’ , ‘SOUND’ and ‘VOLUME’ . Use [SET] to select the required function and then change it by turning the multifunction knob. - Page 13 Device functions Setting the sound You can select three different sounds, which can be adjusted with the rotary control. In addi‐ tion to a human voice, there are also two electronic sounds. Charge state of the battery If the device is running on battery power, the charge state is displayed in the menu. If the charge level is too low, it is advisable to charge the device via the mini USB port.
-
Page 14: Operating The Device
Operating the device Operating the device Training mode The device offers a training mode. Use [TRAIN] to view the desired menu. The number of beats in a defined time interval are cap‐ tured here. The time interval can be set between 10…60 using the multifunction knob and is counted down to 0 during the exercise. -
Page 15: Technical Specifications
Technical specifications Technical specifications Display Six-digit LED display Input connection USB-C Output connection Headphones output (3.5 mm stereo jack socket) Power supply via USB-C Battery Battery type Lithium-ion Voltage 3.7 V Capacity 600 mAh Operating time 10 h Dimensions (W × H × D) 278 mm ×... -
Page 16: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 17 Plug and connection assignment Three-pole 1/8" mini phone jack (stereo, unbalanced) Signal (left) Signal (right) Ground, shielding R1 12" Metronome Practice Pad Drum Pad...
-
Page 18: Cleaning
Cleaning Cleaning Components Clean the accessible parts of the device regularly. The frequency of cleaning depends on the operating environment: moist, smoky or particularly dirty environments may cause a higher accumulation of dirt on the components of the device. Use a dry soft cloth for cleaning. Remove stubborn stains with a slightly damp cloth. -
Page 19: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 20 Protecting the environment Disposal of your old device This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version. Do not dispose with your normal household waste. Dispose of this device through an approved waste disposal firm or through your local waste facility.
- Page 21 Notes R1 12" Metronome Practice Pad Drum Pad...
- Page 22 Notes R1 12" Metronome Practice Pad Drum Pad...
- Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
