SPE rear view
Figure 22 shows an example of an SPE with two SPs (A and B) and the location of the
major hardware components that make up these SPs.
1 Storage processor enclosure
2 Four-port 8-Gb/s (4-Gb/s) FC I/O module
3 Filler panel module
1. In the Block and File (Unified) VNX7500 platform, you could optionally have another pair of 6-Gb/s SAS
I/O modules.
2. The management module in the Block and File (Unified) VNX7500 platform SP comprises two types; one
with a USB port and one without a USB port.
of the SP management module without the USB port.
Figure 22 Example of SPE with two SPs (rear view)
Note: All the Block and File (Unified) VNX7500 platforms have an SPE, a dual SPS, one to
two Control Stations, and one to four Data Mover enclosures. In the following sections, the
illustrations and corresponding tables describe these individual components. These
descriptions are for illustrative purposes only.
The rear of the Block and File (Unified) VNX7500 platform storage processor enclosure
(SPE) does not contain any LEDs
modules in each SP have LEDs.
Note: Figure 22 is a graphical representation of the Block and File (Unified) VNX7500
platform storage processor enclosure rear view with two SPs (each SP has one
management module, one four-port 8-Gb/s FC I/O module, one four-port 6-Gb/s SAS I/O
module, and three filler panel modules).
5 4
4 Four-port 6-Gb/s SAS I/O module
(default)
5 SP management module
"SP management module" on page 34
(Figure 22). Only the management module and the I/O
EMC VNX7500 Hardware Information Guide
System component description
2
3
1
2
shows an example
1
VNX-000601
