INSTALLATION
RLX18
PRÉPARATION / PREPARATION
Diamètre de perçage / Drilling diameter:
1 1/4" (32 mm)
PIÈCES /
PARTS
1
2
3
4
5
Vérifiez que toutes les pièces de votre robinet sont dans l'emballage.
Make sure you have all the parts in hand.
LISTE DES PIÈCES / PARTS LIST
01 Bec / Spout
06 Cartouches / Cartridges
02 Aérateur / Aerator
07 Corps de poignée / Handle body
03
Poignées / Handles
08 Corps de bec / Spout body
04 Rosaces / Flanges
09 Flexibles / Flexibles
05
Ensemble d'attache / Fixing kit
Doc. # DR175-1 / 20-02-2023
ÉTAPES / STEPS
01
6
7
8
9
02
05
03
06
Fixez les flexibles d'entrée d'eau aux valves
d'arrêts respectives.
Thighten both water inlets to each ball valve.
LEXA - RLX18
04
07
www.rubi.ca - 1.888.988.RUBI (7824)
