Connection Diagram; Set Up The Camera - Reolink DUO2-4KWS Operational Instruction

Connection Diagram

Before initial setup, follow the steps below to connect your camera.
1. Connect the camera to a LAN port on your router with an Ethernet cable.
2. Use the power adapter to power on the camera.
Camera
Router
Network Cable
NOTE: The connection diagram takes the WiFi camera as an example and also apply to
the PoE camera. For PoE Camera, please power the camera with a PoE Switch/Injector/
Reolink PoE NVR or a DC 12V power adapter. (not included in the package)
7 English
Power Adapter
Power Cable

Set up the Camera

Download and Launch the Reolink App or Client software, and follow the onscreen
instructions to finish initial setup.
• On Smartphone
Scan to download the Reolink App.
• On PC
Download path of the Reolink Client: Go to
NOTE:
• When setting up the WiFi camera, you need to follow the onscreen instructions to finish the
WiFi configuration first.
• If you are connecting the PoE camera to a Reolink PoE NVR, please set up the camera ia
the NVR interface.
https://reolink.com > Support > App & Client.
English 8
