- Page 1 Titan Laser WUXGA High Brightness Digital Video Projector INSTALLATION & QUICK START GUIDE CONNECTION GUIDE OPERATING GUIDE REFERENCE GUIDE Rev B September 2019 119-712B...
-
Page 2: About This Document
Product revision Because we at Digital Projection continually strive to improve our products, we may change specifications and designs, and add new features without prior notice. Updates may be available online. Please visit the Digital Projection website for all latest documents. -
Page 3: Laser Information
Laser information Digital Projection Ltd. Titan Laser WUXGA Laser information Notes Caution - use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Optical radiation Caution - possibly hazardous optical radiation emitted from this product. Do not stare at operating light source. May be harmful to eyes. This projector is tested according to IEC/EN62471-5:2015 (Photobiological safety of lamps and lamp systems –... -
Page 4: Light Hazard Warning
Digital Projection Ltd. Titan Laser WUXGA Light Hazard Warning Light Hazard Warning Notes The hazard distance is the distance measured from the No direct exposure to the projection lens at which the intensity or energy per unit of beam is permitted, RG3 surface is lower than the applicable exposure limit on the IEC 62471-5:2015. -
Page 5: Introduction
Notes This manual describes both the Titan Laser 37000 WU Series and Titan Laser 29000 WU. Congratulations on your purchase of this Digital Projection product. Your projector has the following key features: WUXGA projector. Support for Frame Sequential and Dual Pipe 3D formats. -
Page 6: Table Of Contents
Digital Projection Ltd. Titan Laser WUXGA Contents Contents Notes About this document Fitting a lens hood Symbols used in this document Fitting a lens stabilizing bracket Product revision Operating the projector Legal notice Switching the projector on Laser information Switching the projector off... - Page 7 Contents Digital Projection Ltd. Titan Laser WUXGA Notes Opening the Menu Overscan Opening a submenu Blanking Exiting menus and closing the OSD Keystone Inside a menu Keystone example Accessing sub menus Keystone settings Executing commands 4 corners Editing projector settings...
- Page 8 Digital Projection Ltd. Titan Laser WUXGA Contents Notes Power on / off Screen requirements Clock adjust Fitting the image to the display PIC mute setting WUXGA images displayed full width OSD settings WUXGA images displayed with a height of 1200 pixels...
- Page 9 Contents Digital Projection Ltd. Titan Laser WUXGA Notes Appendix C: memory scheme and memory items Appendix D: glossary of terms Introduction Rev B September 2019 page 9...
- Page 10 Digital Projection Ltd. Titan Laser WUXGA This page is intentionally left blank Rev B September 2019...
- Page 11 Titan LaserWUXGA High Brightness Digital Video Projector INSTALLATION & QUICK START GUIDE Rev B September 2019 119-712B...
-
Page 12: What's In The Box
Digital Projection Ltd. Titan Laser WUXGA What's in the box? What's in the box? Notes Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Only one remote is supplied with the projector. Save and store the... -
Page 13: Connecting The Power Supply
Connecting the power supply Digital Projection Ltd. Titan Laser WUXGA Connecting the power supply Notes Rest of the World: Use only the power cable provided. 1. Firmly push the mains connector into the socket 2. Rotate the connector 90° clockwise to lock it in place... -
Page 14: Projector Overview
Digital Projection Ltd. Titan Laser WUXGA Projector overview Projector overview Notes 1. Eye bolts 2. Connections panel 3. Stacking pins (x4) 4. Adjustable feet (x4) 5. Stacking cups (x4) 6. Control panel 7. Mains socket and switch Front View Installation & Quick Start Guide... -
Page 15: Control Panel
Control panel Digital Projection Ltd. Titan Laser WUXGA Control panel Notes 1. POWER AUTO SYNC and Switches the projector on and off (STANDBY). ASPECT do not work AUTO CENTER Indicator: POWER INPUT SYNC ASPECT PIC MUTE HOTKEYS when the projector uses... - Page 16 Digital Projection Ltd. Titan Laser WUXGA Control panel 10. STATUS Notes Off = no problem Flashing red (continuously) = cover error Flashing red (cycles of four flashes) = fan error On, red = system error 11. MENU Displays and exits the OSD.
-
Page 17: Remote Control
Remote control Digital Projection Ltd. Titan Laser WUXGA Remote control Notes 1. Power ON / OFF Turns power on and off. 2. Pic Mute OPEN / CLOSE The PIC Mute setting is Shows and hides the projected image. defined in the setup menu. - Page 18 Digital Projection Ltd. Titan Laser WUXGA Remote control 11. LENS adjustment Notes FOCUS IN / OUT: adjust focus. If focus cannot be achieved using the focus SHIFT: press and hold this button, then use the Navigation arrow buttons to move the in / out feature, press Shift lens.
- Page 19 Remote control Digital Projection Ltd. Titan Laser WUXGA 17. DISPLAYPORT 1 / R / numeric input 4 Notes Select DisplayPort 1 input. 18. HD-T / G / numeric input 5 Select the HDBaseT input. 19. VGA / 3D / numeric input 7...
-
Page 20: Infrared Reception
Digital Projection Ltd. Titan Laser WUXGA Remote control Infrared reception Notes The projector has infrared sensors at the front and back. 40˚ The angle of acceptance is 40°. Make sure that the remote control is within the angle of acceptance when trying to control the projector. -
Page 21: Positioning The Screen And Projector
Positioning the screen and projector Digital Projection Ltd. Titan Laser WUXGA Positioning the screen and projector Notes 1. Install the screen, ensuring that it is in the best position for viewing by your Always allow the audience. projector to cool for 5 2. -
Page 22: Roll And Pitch
Digital Projection Ltd. Titan Laser WUXGA Positioning the screen and projector Roll and pitch Notes The projector can be operated in numerous positions. In portrait mode, it is recommended to position the projector with inputs facing upward, as shown in the 360˚... -
Page 23: Stacking And Rigging
Positioning the screen and projector Digital Projection Ltd. Titan Laser WUXGA Stacking and rigging Notes The projector can be stacked using the pin and cups that are located on top and underneath the projector. The pin and cups can also be used to attach a mounting Do not use the threaded rail. -
Page 24: Using The Eye Bolts
Digital Projection Ltd. Titan Laser WUXGA Positioning the screen and projector Using the eye bolts Notes Four eye-bolts are fitted to the top of the projector to enable the flying of the projector using steel wire or chains. This system should only... -
Page 25: Threaded Suspension Cables
Positioning the screen and projector Digital Projection Ltd. Titan Laser WUXGA Threaded suspension cables Notes Refer to the following guidelines when threading the suspension cable through the eye-bolts and 45° 45° connecting both ends to suspension points. 45° 45° The suspension cable can exit the eye-bolts at an angle of up to 45° around the eye ring. -
Page 26: Changing The Lens
Digital Projection Ltd. Titan Laser WUXGA Changing the lens Changing the lens Notes Inserting a new lens Before changing the lens, always make sure 1. Turn the lens release lever clockwise so that it is pointing upwards, to open the lock fully. -
Page 27: Fitting A Lens Hood
Changing the lens Digital Projection Ltd. Titan Laser WUXGA Fitting a lens hood Notes 1. Remove the six screws. FDA regulations requires 2. Remove the lens glass. that a lens hood is permanently fitted when 3. Place hood over the lens, aligned with the screw holes. -
Page 28: Fitting A Lens Stabilizing Bracket
Digital Projection Ltd. Titan Laser WUXGA Changing the lens Fitting a lens stabilizing bracket Notes 1. Remove the cover from the front of the projector In some applications and 2. Remove the lens mount and lens projector orientations, it may be necessary to fit the stabilizing bracket to the lens mount. - Page 29 Changing the lens Digital Projection Ltd. Titan Laser WUXGA 6. Remove the two M2 screws from the fixed lens bracket Notes 7. Remove the fixed lens bracket Installation & Quick Start Guide Rev B September 2019 page 29...
- Page 30 Digital Projection Ltd. Titan Laser WUXGA Changing the lens 8. Place the stabilizing bracket on to the lens collar Notes 9. Screw in the two M2 screws to fix the stabilizing bracket to the lens collar 10. Place the lens collar on to the lens 11.
- Page 31 Changing the lens Digital Projection Ltd. Titan Laser WUXGA 13. Place the lens into the projector Notes 14. Screw the two fixing screws into the lens stabilizing bracket 15. Place the cover over the front of the projector Installation & Quick Start Guide...
-
Page 32: Operating The Projector
On the projector control panel, the POWER button. provided. The POWER indicator begins flashing green as the projector powers up. When the flashing stops, the POWER indicator lights solid green and the Digital Projection Ensure that the power logo appears on the screen. The projector is switched on and projecting. -
Page 33: Adjusting The Lens
Operating the projector Digital Projection Ltd. Titan Laser WUXGA Adjusting the lens Notes The lens can be adjusted using the Lens menu, or using the lens buttons on the remote control. Lens menu The Lens menu provides access to the Lens Control setting and the Lens Center command. - Page 34 Digital Projection Ltd. Titan Laser WUXGA This page is intentionally left blank Rev B September 2019...
- Page 35 Titan LaserWUXGA High Brightness Digital Video Projector CONNECTION GUIDE Rev B September 2019 119-712B...
-
Page 36: Signal Inputs
Digital Projection Ltd. Titan Laser WUXGA Signal inputs Signal inputs Notes Digital inputs and outputs 1. HDMI 1 / HDMI 2 For simultaneous HDMI 2.0 inputs supporting HDCP 2.2. Connect an HDBaseT and LAN HDMI cable to the connector. connectivity, a third-party 2. -
Page 37: Edid On The Displayport, Hdmi, And Hdbaset Inputs
Signal inputs Digital Projection Ltd. Titan Laser WUXGA EDID on the DisplayPort, HDMI, and HDbaseT inputs Notes If you are using a computer graphics card or another source that obeys the EDID protocol, the source will automatically configure itself to suit the capability of the projector. -
Page 38: 3D Connections
Digital Projection Ltd. Titan Laser WUXGA 3D connections 3D connections Notes 1. Sync In / Sync Out Sync In is the 3D sync input signal. Connect the 3D sync from your graphics card or server. Sync Out is the 3D sync output signal. Enables 3D from... -
Page 39: 3D Sync
3D connections Digital Projection Ltd. Titan Laser WUXGA 3D Sync Notes 1. 3D Input 2. 3D Sync In 3. 3D Sync IR 4. IR emitter or Zscreen Connection Guide Rev B September 2019 page 39... -
Page 40: Control Connections
Digital Projection Ltd. Titan Laser WUXGA Control connections Control connections Notes 1. Trigger 1 & Trigger 2 For a list of all commands The Trigger outputs are defined in the Setup menu. used to control the SYNC OUT SYNC IN... -
Page 41: Lan Connection Examples
Digital Projection Ltd. Titan Laser WUXGA LAN connection examples Notes The projector’s features can be controlled via a LAN connection, using Digital Projection’s Projector Controller application or a terminal emulation program. With a LAN connection the projector can serve a web page offering basic projector controls. -
Page 42: Rs232 Connection Example
Digital Projection Ltd. Titan Laser WUXGA Control connections RS232 connection example Notes All of the projector’s features can be controlled via a serial connection, using commands described in the Protocol Guide. The Protocol Guide is available separately Straight through cable... - Page 43 Titan LaserWUXGA High Brightness Digital Video Projector OPERATING GUIDE Rev B September 2019 119-712B...
-
Page 44: Using The Menus
Digital Projection Ltd. Titan Laser WUXGA Using the menus Using the menus Notes Opening the Menu Access the various menus using AUTO CENTER POWER INPUT SYNC ASPECT PIC MUTE HOTKEYS either the projector control panel or LIGHT TEMP LENS the remote control. On either device: 1. -
Page 45: Exiting Menus And Closing The Osd
Using the menus Digital Projection Ltd. Titan Laser WUXGA Exiting menus and closing the OSD Notes To go back to the previous page: Main Menu Main Menu 1. Press EXIT. Input HDMI 1 ▲ To close the OSD: Test Pattern ►... -
Page 46: Accessing Sub Menus
Digital Projection Ltd. Titan Laser WUXGA Using the menus Accessing sub menus Notes Use the UP and DOWN arrow buttons to highlight the sub-menu, then press ENTER/OK. Executing commands If the item contains a command, highlighting it reveals an OK... -
Page 47: Editing Projector Settings
Using the menus Digital Projection Ltd. Titan Laser WUXGA Editing projector settings Notes If the highlighted menu item contains a list of values to choose from, you can change the value by doing the Menu Name Some menu items may be... -
Page 48: Editing Numeric Values
Digital Projection Ltd. Titan Laser WUXGA Using the menus Editing numeric values Notes Some parameters take numeric values without using sliders - for example, color matching values or IP Data addresses. x: 0.658 y: 0.339 1. Use the UP and DOWN arrow buttons to highlight the row containing the numeric field you wish to edit. -
Page 49: Using The Projector
Using the projector Digital Projection Ltd. Titan Laser WUXGA Using the projector Notes Main menu Input Main Menu Main Menu See Signal inputs on Press ENTER/OK to open the list of available inputs. page 36 for information Use the UP and DOWN arrow buttons to select an... -
Page 50: Lens Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector Lens menu Notes Lens Lock Lens When this feature is On, all other Lens menu items are disabled. Lens Lock Lens Control Opens a sub-menu, see below. Lens Control ► Center Lens Center Lens Centers the lens. -
Page 51: Lens Memory
Using the projector Digital Projection Ltd. Titan Laser WUXGA Lens memory Notes This menu allows you to load, save and delete up to ten lens presets, containing position, zoom, focus and shift Lens Memory adjustment information. Load Memory ► For example, if using different screen sizes and aspect ratios, you can save zoom, focus and positioning for Save Memory ►... -
Page 52: Image Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector Image menu Notes Dynamic Black Image The following settings are Set to On to allow for increased contrast in darker scenes by modulating the light source. not available with input Light Off Timer... - Page 53 Using the projector Digital Projection Ltd. Titan Laser WUXGA HDR Screen sizes Screen width (cm) Notes Model Lumens 400 NIT 500 NIT 1000 NIT 4000 NIT Titan Laser WU 29,000 607.6cm 543.5cm 384.3cm 192.2cm Titan Laser WU 37,000 686.4cm 613.9cm 434.1cm 217.1cm...
-
Page 54: Color Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector Color menu Notes Color Color Space Auto Color Mode ColorMax ColorMax Peak Manual Color Matching ► Color Temperature Native Gains and Lifts ► Color space In most cases, the Auto setting determines the correct colorspace to use. If it does not, you can choose a specific... -
Page 55: Color Mode
Using the projector Digital Projection Ltd. Titan Laser WUXGA Color mode Notes The projector can work in the following color modes: ColorMax, Manual Color Matching, Color Temperature Color Only one color mode can and Gains and Lifts. be selected at a time. -
Page 56: Manual Color Matching
Digital Projection Ltd. Titan Laser WUXGA Using the projector Manual color matching Notes 1. Set Color Mode to Manual Color Matching. Manual Color Matching 2. Open the Manual Color Matching submenu. Auto Test Pattern Here you can do the following: ►... -
Page 57: Color Matching Parameters Explained
Using the projector Digital Projection Ltd. Titan Laser WUXGA Color matching parameters explained Notes The levels of hue, saturation and gain in the Manual Color Matching menu change the color values in the following ways: 1. Hue Specifies the position of each color (red, yellow, green, cyan, blue and magenta) relative to its neighboring colors. -
Page 58: Color Temperature
Digital Projection Ltd. Titan Laser WUXGA Using the projector Color temperature Notes 1. Set Color Mode to Color Temperature. Color 2. Navigate to the Color Temperature setting. Choose a value from 3200K (warmer) to 9300K (cooler) or Color Space Auto Native (no correction). -
Page 59: Geometry Menu
Using the projector Digital Projection Ltd. Titan Laser WUXGA Geometry menu Notes This menu allows you to compensate for image distortions caused by an unusual projection angle or irregular Geometry Aspect Ratio, Digital screen surface. Zoom and Overscan are Aspect Ratio... -
Page 60: Theaterscope Setting
Digital Projection Ltd. Titan Laser WUXGA Using the projector Theaterscope setting Notes The TheaterScope setting is used in combination with an anamorphic lens to restore 2.35: images packed into a 16:9 frame. Such images are projected with black TheaterScope is used with lines at the top and bottom of the 16:9 screen to make up for the difference in aspect ratios. -
Page 61: Digital Zoom
Using the projector Digital Projection Ltd. Titan Laser WUXGA Digital zoom Notes Digital zooming enlarges a section of the image, while the area outside the enlarged section is cropped out to Digital Zoom Digital Zoom is not preserve the overall image size. -
Page 62: Overscan
Digital Projection Ltd. Titan Laser WUXGA Using the projector Overscan Notes Use this setting to compensate for noisy or badly defined image edges. Geometry Overscan is not available with input HDMI 3 or HDMI Crop removes unwanted artifacts from the edges of your image by cropping the edges. -
Page 63: Blanking
Using the projector Digital Projection Ltd. Titan Laser WUXGA Blanking Notes Use this feature to: Blanking fit an odd-sized screen; cut off timecode dots in the top line of a picture; Bottom cut off subtitles, etc. Left Select the edge you wish to blank and use the LEFT and RIGHT arrow buttons to determine the amount of Right correction. -
Page 64: Keystone
Digital Projection Ltd. Titan Laser WUXGA Using the projector Keystone Notes Use this setting to compensate for any distortion caused by the projector being in a different horizontal or vertical Keystone Max rotation in Keystone plane to the screen. is reduced from normal... -
Page 65: Keystone Example
Using the projector Digital Projection Ltd. Titan Laser WUXGA Keystone example Notes The projector is positioned at an angle The resulting image is distorted The image is corrected when Keystone is The aspect ratio is corrected when the correct applied, but the aspect ratio is incorrect... -
Page 66: Keystone Settings
Digital Projection Ltd. Titan Laser WUXGA Using the projector Keystone settings Notes 1. Projector to the left The projector is positioned to the left of the screen. To correct, apply a positive Horizontal Keystone value using the RIGHT arrow button. -
Page 67: Corners
Using the projector Digital Projection Ltd. Titan Laser WUXGA 4 corners Notes For each corner, apply horizontal and / or vertical correction as necessary to restore the rectangular shape of the 4 Corners Corner corrections image. provide a simple setup for Top Left Corner ►... -
Page 68: Top Right Corner Example
Digital Projection Ltd. Titan Laser WUXGA Using the projector Top right corner example Notes In this illustration, the top right corner requires both horizontal and vertical correction. Top Right Corner Adjustment Top Right Corner x Top Right Corner y Operating Guide... -
Page 69: Rotation
Using the projector Digital Projection Ltd. Titan Laser WUXGA Rotation Notes Use this feature for example to correct a mounting error causing the image not to be level with the screen. Rotation Rotation Reset Operating Guide Rev B September 2019... -
Page 70: Rotation Example
Digital Projection Ltd. Titan Laser WUXGA Using the projector Rotation example Notes 1. DMD™ area The DMD™ is not rotated. It still covers the area that would be occupied by the image without correction. 2. Rotated image The image is smaller than the surrounding DMD™ area. It is scaled in order to remain within the DMD™... -
Page 71: Pincushion / Barrel
Using the projector Digital Projection Ltd. Titan Laser WUXGA Pincushion / barrel Notes Pincushion or barrel distortions are the result of poor or incorrect tensioning of the screen or using a surface that Pincushion / Barrel Make sure that the lens is not flat. -
Page 72: Arc
Digital Projection Ltd. Titan Laser WUXGA Using the projector Notes This feature is similar to Pincushion / Barrel but allows you to apply curvature to each edge of the image Please note that a positive independently so you can have any combination of corrections. -
Page 73: Custom Warp
Using the projector Digital Projection Ltd. Titan Laser WUXGA Custom warp Notes This feature permits selection of predefined User warp maps. Use the Projector Controller PC application to Custom Warp create the custom warp maps. Custom warp maps provide non-linear curvature correction for curved or spherical screens and other irregular User 1 shaped surfaces such as building mapping. -
Page 74: Edge Blend Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector Edge blend menu Notes Use this menu to blend together images from an array of two or more projectors. The feature feathers the light Edge Blend When Edge Blend is set to... -
Page 75: Blend Start
Using the projector Digital Projection Ltd. Titan Laser WUXGA Blend start Notes Use the blend start options to deactivate pixels at the edge of the image and set the start point for the blended Blend Start region. Use the LEFT and RIGHT arrow buttons to set the start point of the blended regions: 1. -
Page 76: Blend Width
Digital Projection Ltd. Titan Laser WUXGA Using the projector Blend width Notes Use the LEFT and RIGHT arrow buttons to set the width of the blended regions: Blend Width 1. Top 2. Bottom Bottom 3. Left Left 4. Right Right... -
Page 77: Black Level Uplift
Using the projector Digital Projection Ltd. Titan Laser WUXGA Black level uplift Notes Black in the blended regions appears less dark than in the rest of the image. To compensate for this, use this Black Level Uplift Enable Align Pattern from... -
Page 78: 3D Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector 3D menu Notes Use this menu to enable, disable and set up 3D input, as follows: 3D video is only possible 3D Format on the HDMI 3 and HDMI 3D Format Auto Off, Dual Pipe and Frame Sequential. -
Page 79: Types
Using the projector Digital Projection Ltd. Titan Laser WUXGA 3D types Notes To display a 3D image if is first necessary to select the 3D format. This can either be Frame Sequential or Dual Pipe. These formats are described below: Dual Pipe (LEFT and RIGHT) The left and right eye images are delivered on two separate HDMI links, which the projector will interleave for 3D display. -
Page 80: Some 3D Settings Explained
Digital Projection Ltd. Titan Laser WUXGA Using the projector Some 3D settings explained Notes Dark time In order to achieve maximum light output and Banding can be caused if the image is displayed before each a smooth grayscale, whilst Fully On eye of the 3D switching glasses or ZScreen is not fully open. -
Page 81: Sync Offset
Using the projector Digital Projection Ltd. Titan Laser WUXGA Sync offset Notes The sync signal from the 3D server will be in phase with the Incoming video frames generated by its graphics card. However, to compensate for switching delays in the glasses or ZScreen,... -
Page 82: Laser Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector Laser menu Notes Power Mode Laser The projector must be Eco will automatically set the laser power to 80%. connected via LAN to the Power Mode Normal Normal will set the power to 100%. -
Page 83: Setup Menu
Startup Logo Choose from Off, Original and User. Select original to display the Digital Projection Ltd. logo on startup. Select User to display a custom logo. Use the custom logo upload tool to set the custom logo for the User option. - Page 84 Digital Projection Ltd. Titan Laser WUXGA Using the projector Trigger1 and Trigger 2 Setup Notes Choose from Screen, 5:4, 4:3, 16:10, 16:9, 1.88, 2.35, TheaterScope, Source, Unscaled or RS232 to ▲ determine what will cause each trigger output to activate.
-
Page 85: Colormax
Using the projector Digital Projection Ltd. Titan Laser WUXGA Hotkey Setting Setup Notes Access this submenu to set the option for each hotkey. ▲ Keypad Button Backlight Smear reduction is not Choose from On or Off. Select On to switch the keypad backlight on. This will light the keypad controls on Hotkey Setting ►... -
Page 86: Measured Data/ Target Data
Digital Projection Ltd. Titan Laser WUXGA Using the projector Measured data/ target data Notes 1. Use the UP and DOWN arrow buttons to highlight a Measured Data Target Data - User1 color, then use the LEFT and RIGHT arrow buttons to navigate to the x or y coordinate. -
Page 87: Power On / Off
Using the projector Digital Projection Ltd. Titan Laser WUXGA Power on / off Notes Auto Power Off Power on/off Management Set this to On if you want the projector to go into STANDBY mode when no input source is detected for 20 minutes. -
Page 88: Clock Adjust
Digital Projection Ltd. Titan Laser WUXGA Using the projector Clock adjust Notes Use this menu to set date (in dd:MM:yyyy format), time (in HH:mm format) and time zone. Clock Adjust The date and time set here will affect any schedule created within the Power On/Off menu. -
Page 89: Osd Settings
Using the projector Digital Projection Ltd. Titan Laser WUXGA OSD settings Notes Language sets the OSD language. OSD Settings Menu Position determines where the OSD should appear on the screen when activated. Language English Menu Transparency sets OSD transparency between 0% (no transparency), 25%, 50% and 75%. -
Page 90: Edid Mode
Digital Projection Ltd. Titan Laser WUXGA Using the projector EDID Mode Notes Each signal input type is available in the menu. Select the appropriate frame rate and display resolution for each EDID Mode input. HDMI 1 4K/60 HDR HDMI 2... -
Page 91: Network Menu
Using the projector Digital Projection Ltd. Titan Laser WUXGA Network menu Notes Network Setup Network Access this submenu to edit the network settings for the projector Network Setup ► Art-Net Setup Access this submenu to edit the Art-Net network settings for the projector Art-Net Setup ►... -
Page 92: Network Setup
Digital Projection Ltd. Titan Laser WUXGA Using the projector Network setup Notes DHCP, IP, Subnet Mask, Gateway, DNS Network Setup Set DHCP to On if the IP address is to be assigned by a DHCP server, or Off if it is to be set here. -
Page 93: Art-Net Channel Setting
Using the projector Digital Projection Ltd. Titan Laser WUXGA Art-net channel setting Notes Chanel 1-5 Art-Net Channel Setting Choose from None, Power, PIC Mute, Power Level, Input and Channel Control. Select the projector functions that are associated with each art-net channel. -
Page 94: Pip Menu
Digital Projection Ltd. Titan Laser WUXGA Using the projector PIP menu Notes PIP Turn PIP on and off. PIP functionality is not Source Select an input source for the PIP image. Any combinations are possible between main and PIP available with inputs input source, as long as one of the inputs is either DisplayPort or 3G-SDI. -
Page 95: Information Menu
Using the projector Digital Projection Ltd. Titan Laser WUXGA Information menu Notes This menu gives information about software and hardware configuration, input source and laser operating times Information It also allows you to restore the factory default settings. Model Name... -
Page 96: System Status
Digital Projection Ltd. Titan Laser WUXGA Using the projector System status Notes System Status Atmospheric Pressure 98988 Pa (116m) AC Voltage 180V - 264V Altitude Mode Auto Laser Power 100% License Key License Pass, Timeout,NotExpired Constant Brightness Thermal status Thermal Status Inlet/DMD Temp. -
Page 97: Factory Reset
Using the projector Digital Projection Ltd. Titan Laser WUXGA Factory reset Notes To restore the factory default settings: Information Factory reset does not reset the Network settings, 1. Navigate to Factory Reset and press ENTER/OK. Model Name TitanLaser 33000 4K-UHD or High Altitude mode 2. -
Page 98: Served Web Pages
Digital Projection Ltd. Titan Laser WUXGA Served web pages Served web pages Notes The served web pages allow you to control the projector remotely via LAN. The default IP address is 192.168.0.100. Operating Guide Rev B September 2019 page 98... - Page 99 Served web pages Digital Projection Ltd. Titan Laser WUXGA Notes Operating Guide Rev B September 2019 page 99...
- Page 100 Digital Projection Ltd. Titan Laser WUXGA Served web pages Notes Operating Guide Rev B September 2019 page 100...
- Page 101 Served web pages Digital Projection Ltd. Titan Laser WUXGA Notes Operating Guide Rev B September 2019 page 101...
- Page 102 Digital Projection Ltd. Titan Laser WUXGA Served web pages Notes Operating Guide Rev B September 2019 page 102...
- Page 103 Served web pages Digital Projection Ltd. Titan Laser WUXGA Notes Operating Guide Rev B September 2019 page 103...
- Page 104 Digital Projection Ltd. Titan Laser WUXGA Served web pages Notes Operating Guide Rev B September 2019 page 104...
- Page 105 Served web pages Digital Projection Ltd. Titan Laser WUXGA Notes Operating Guide Rev B September 2019 page 105...
- Page 106 Digital Projection Ltd. Titan Laser WUXGA Served web pages Notes Operating Guide Rev B September 2019 page 106...
- Page 107 Titan LaserWUXGA High Brightness Digital Video Projector REFERENCE GUIDE Rev B September 2019 119-712B...
-
Page 108: Choosing A Lens
Digital Projection Ltd. Titan Laser WUXGA Choosing a lens Choosing a lens Notes A number of lenses are available. Which lens you choose depends on the screen size, image aspect ratio, throw distance and light output. See Fitting a lens hood on page 27 for more... -
Page 109: Basic Calculation
Choosing a lens Digital Projection Ltd. Titan Laser WUXGA Basic calculation Notes Identify the required lens by calculating the throw ratio. The basic calculation on this page does not take A throw ratio is the ratio of the throw distance to the screen width into consideration DMD™... -
Page 110: Basic Calculation Example
Digital Projection Ltd. Titan Laser WUXGA Choosing a lens Basic calculation example Notes 1. Calculate the throw ratio using the formula. The basic calculation on Your screen is 4.5m wide and you wish to place the projector approximately 11m from the... -
Page 111: Full Lens Calculation
Choosing a lens Digital Projection Ltd. Titan Laser WUXGA Full lens calculation Notes Introducing TRC The choice of lens will affect the image size and will address discrepancies between the DMD™ TRC can only be applied if resolution and the source. -
Page 112: Calculating Trc
Digital Projection Ltd. Titan Laser WUXGA Choosing a lens Calculating TRC Notes To calculate TRC, use the following formula: TRC can only be applied if greater than 1. If TRC is 1 or less, disregard it and calculate the throw ratio TRC table using the basic formula. -
Page 113: Full Lens Calculation Example
Choosing a lens Digital Projection Ltd. Titan Laser WUXGA Full lens calculation example Notes Your screen is 4.5m wide; you wish to place the projector approximately 11m from the screen. The source is 4:3. INFORMATION YOU NEED FOR THESE CALCULATIONS 1. -
Page 114: Screen Requirements
Digital Projection Ltd. Titan Laser WUXGA Screen requirements Screen requirements Notes Fitting the image to the display If the source image supplied to the projector is smaller than the WUXGA resolution, the image will not fill the display. The following examples show how a number of common formats may be displayed, depending on your DMD™... -
Page 115: Wuxga Images Displayed Full Height
Screen requirements Digital Projection Ltd. Titan Laser WUXGA WUXGA images displayed full height Notes 4:3 = 1.33:1 = 1596 pixels WUXGA = 16:10 = 1.6:1 = 1920 pixels Diagonal screen sizes Screen sizes are sometimes specified by their diagonal size (D). When dealing with large screens... -
Page 116: Positioning The Image
Digital Projection Ltd. Titan Laser WUXGA Positioning the image Positioning the image Notes The normal position for the projector is at the centre of the See Lens control on screen. However, you can set the projector above or below page 50 for more... - Page 117 Positioning the image Digital Projection Ltd. Titan Laser WUXGA Any single adjustment outside the Notes ranges specified on the following page may result in an unacceptable See Lens control on level of distortion, particularly at the page 50 for more corners of the image, due to the...
-
Page 118: Aspect Ratios Explained
Digital Projection Ltd. Titan Laser WUXGA Aspect ratios explained Aspect ratios explained Notes The appearance of a projected image on the screen depends on a combination of the following: The display resolution is WUXGA with a 1920 x 1200 resolution, corresponding to an aspect ratio of 16:10... -
Page 119: Source: 16:9
Aspect ratios explained Digital Projection Ltd. Titan Laser WUXGA Source: 16:9 Notes Aspect Ratio 16:10 Aspect Ratio: Source / 16:9 Source: 16:10 (native) Aspect Ratio: Source / 16:10 Reference Guide Rev B September 2019 page 119... -
Page 120: Aspect Ratio Example: Theatrescope
Digital Projection Ltd. Titan Laser WUXGA Aspect ratios explained Aspect ratio example: TheatreScope Notes The TheaterScope setting is used in combination with an anamorphic lens to restore 2.35:1 images packed into a 16:9 frame. Such images are projected with black lines at the top and bottom of the 16:9 screen to make up for the difference in aspect ratios. -
Page 121: Appendix A: Supported Signal Input Modes
Appendix A: supported signal input modes Digital Projection Ltd. Titan Laser WUXGA Appendix A: supported signal input modes Notes 2D formats HDMI 1/2 & HDBaseT HDMI3/4 Signal Output Frame Frame Display Resolution Remarks Format Rate (Hz) Port Rate (Hz) 8/10/12-... - Page 122 Digital Projection Ltd. Titan Laser WUXGA Appendix A: supported signal input modes HDMI 1/2 & HDBaseT HDMI3/4 Notes Signal Output Frame Frame Display Resolution Remarks Format Rate (Hz) Port 8/10/12- Rate (Hz) 8-bit 10-bit 12-bit 50 at 4K display 100 at ü...
- Page 123 Appendix A: supported signal input modes Digital Projection Ltd. Titan Laser WUXGA HDMI 1/2 & HDBaseT HDMI3/4 Notes Signal Output Frame Frame Display Resolution Remarks Format Rate (Hz) Port 8/10/12- Rate (Hz) 8-bit 10-bit 12-bit ü ü ü ü ü...
-
Page 124: Formats
Digital Projection Ltd. Titan Laser WUXGA Appendix A: supported signal input modes 3D formats Notes Input Source Output Frame Rate V-Freq H Freq. Standard Remarks Resolution V-Total Dual-pipe HDMI 3 (Hz) (kHz) (Hz) HDMI3/4 Frame Maintained aspect ratio in 1080p100 1920x1080 100.00... -
Page 125: Sdi Formats
Appendix A: supported signal input modes Digital Projection Ltd. Titan Laser WUXGA SDI formats Notes Timing SDI Link Mode Signal Standards Color Encode Sampling Structure Bit Depth NTSC SMPTE 259M-C 270Mbps SD YCbCr 4:2:2 SMPTE 259M-C 270Mbps SD YCbCr 4:2:2 1035i60 SMPTE 292M 1.5Gbps HD... -
Page 126: Appendix B: Wiring Details
Digital Projection Ltd. Titan Laser WUXGA Appendix B: wiring details Appendix B: wiring details Notes Signal inputs and outputs HDMI 1 and 2 19 way type A connector 1. TMDS Data 2+ 2. TMDS Data 2 Shield HDMI: pin view of panel connector 3. -
Page 127: Displayport
Appendix B: wiring details Digital Projection Ltd. Titan Laser WUXGA DisplayPort Notes DisplayPort 1.2 Pin 1 ML_Lane 0 (p) Lane 0 (positive) Pin 2 Ground Pin 3 ML_Lane 0 (n) Lane 0 (negative) Pin 4 ML_Lane 1 (p) Lane 1 (positive) -
Page 128: 3G-Sdi In, 3G-Sdi Out
Digital Projection Ltd. Titan Laser WUXGA Appendix B: wiring details 3G-SDI in, 3G-SDI out Notes 75 ohm BNC 3G-SDI connector HDBaseT input RJ45 socket. HDBaseT / LAN Reference Guide Rev B September 2019 page 128... -
Page 129: Control Connections
Appendix B: wiring details Digital Projection Ltd. Titan Laser WUXGA Control connections Notes Only one remote RJ45 socket (Shared with HDBaseT) connection (RS232 or LAN) should be used at any one time. HDBaseT / LAN RS232 9 way D-type connector 1. - Page 130 Digital Projection Ltd. Titan Laser WUXGA Appendix C: memory scheme and memory items Appendix C: memory scheme and memory items Notes Below is a summary of the OSD parameters that can be saved in the memory presets. Global Per Input Memory...
- Page 131 Appendix C: memory scheme and memory items Digital Projection Ltd. Titan Laser WUXGA Global Per Input Memory Notes Item Remark Memory (Preset A/B/C/D) input ◎ OverScan ◎ Warping Mode ◎ H Keystone ◎ V Keystone ◎ Rotation ◎ Lens Throw Ratio ◎...
- Page 132 Digital Projection Ltd. Titan Laser WUXGA Appendix C: memory scheme and memory items Global Per Input Memory Notes Item Remark Memory (Preset A/B/C/D) input ◎ Ir Code ◎ OSD Language ◎ OSD Menupos ◎ OSD Trans ◎ OSD Timer ◎...
- Page 133 Appendix D: glossary of terms Digital Projection Ltd. Titan Laser WUXGA Appendix D: glossary of terms Notes 1080p An HDTV resolution which corresponds to 1920 x 1080 pixels (a widescreen aspect ratio of 16:9). 3D active glasses Wireless battery-powered glasses with LCD shutters. Synchronization information is communicated to the glasses by means of an infrared (IR) or radio frequency (RF) emitter which is connected to the Sync Out terminal on the projector.
- Page 134 Digital Projection Ltd. Titan Laser WUXGA Appendix D: glossary of terms Notes Blanking (projection) The ability to intentionally turn off, that is, set to black, areas around the edges of the projected image. It is sometimes referred to as “curtains” since it can be used to blank an area of image that literally falls on the curtains at the side of the screen in a movie theater.
- Page 135 Appendix D: glossary of terms Digital Projection Ltd. Titan Laser WUXGA Contrast (electronic control) Notes The adjustment of the white point of the image without affecting the black point. This increases the intensity range of the displayed image. Contrast (optical) The intensity difference between the darkest and lightest areas of the screen.
- Page 136 Digital Projection Ltd. Titan Laser WUXGA Appendix D: glossary of terms Edge tear Notes An artifact observed in interlaced video where the screen appears to be split horizontally. Edge tears appear when the video feed is out of sync with the refresh rate of the display device.
- Page 137 Appendix D: glossary of terms Digital Projection Ltd. Titan Laser WUXGA Notes HDCP (High-bandwidth Digital Content Protection) An encryption scheme used to protect video content. HDTV (High Definition Television) A television system with a higher resolution than SDTV and EDTV. It can be transmitted in various formats, notably 1080p and 720p.
- Page 138 Digital Projection Ltd. Titan Laser WUXGA Appendix D: glossary of terms Luminance Notes Also known as ‘Y’, this is the part of a Component Video signal which affects the brightness, i.e. the black and white part. Noise Electrical interference displayed on the screen.
- Page 139 Appendix D: glossary of terms Digital Projection Ltd. Titan Laser WUXGA Primary colors Notes Three colors any two of which cannot be mixed to produce the third. In additive color television systems the primary colors are red, green and blue.
- Page 140 Digital Projection Ltd. Titan Laser WUXGA Appendix D: glossary of terms Notes Test pattern A still image specially prepared for testing a projection system. It may contain various combinations of colors, lines and geometric shapes. TheaterScope An aspect ratio used in conjunction with a special anamorphic lens to display 2.35:1 images packed into a 16:9 frame.
- Page 141 Appendix D: glossary of terms Digital Projection Ltd. Titan Laser WUXGA Notes This is the luminance input (brightness) from a Component Video signal. Color difference signals used with ‘Y’ for analog Component Video inputs. They provide information about the signal color. Not to be confused with Cr, ZScreen A special kind of light modulator which polarizes the projected image for 3D viewing.
- Page 142 Contact Information: Digital Projection Japan Digital Projection Asia Digital Projection China Digital Projection Inc. Digital Projection Limited 〒 105-0012 東 京 都 港 区 芝 大 門 16 New Industrial Road, #02-10 中 国 北 京 市 朝 阳 区 芍 药 居 北...
Need help?
Do you have a question about the 119-712B and is the answer not in the manual?
Questions and answers
