PCM-24BXWF
iDoor Box with RED Certified Wireless WIFI Module
PCM-24BX4G
iDoor Box with RED Certified Wireless LTE Module
Startup Manual
Packing List
Before installation, please make sure that you have:
• 1 x iDoor box with wireless communication module and
SMA cables inside.
• 2 x Antenna
• 1 x Startup manual
• 1 x Warranty card
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Please make sure your system already assembled with
PCM-24BXBK which includes internal bracket, signal cable
and mPCIE card, then you can use iDoor box.
Contact sales if needed.
Documentation/Software Support Guide
The support documentation and drivers can be accessed
from the Advantech website.
• Documentation
- Datasheet
For more information on this and other Advantech
products, please visit our website at:
https://www.advantech.com/
For technical support and service:
https://support.advantech.com/support/new_de-
fault.aspx
This startup manual is for PCM-24BX series.
Part No. 204324BX00
Installation
Please follow the steps as below.
1. Please make sure your system already assembled with
2. Remove the blank iDoor cover.
Edition 1
March 2020
PCM-24BXBK.
Unscrew to remove the blank iDoor cover.
PCM-24BX Series Startup Manual 1
