Advantech PCM-23C1CF Manual

PCM-23C1CF
1 x CFast slot with cover protection
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
ƒ 1 x CFast I/O plate with 1 x iDoor bracket
ƒ 1 x Startup manual
ƒ 1 x Warranty card
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Installation
The PCM-23C1CF module with iDoor technology
supports the following iAutomation computing platforms:
ƒ UNO-2000 standard mount series
ƒ UNO-1000 DIN rail mount series
ƒ UNO-3000 wallmount series
ƒ 4:3 TPC-xx51T/xx82, TPC-5000 panel PCs
ƒ 16:9 TPC-xx51WP/xx81WP, TPC-5000 panel PCs
*Note: An additional SATA cable may be required to
install the PCM-23C1CF module on a TPC
system.
Documentation/Software Support Guide
Advantech's PCM-23C1CF module is a SATAII (3G/s)
to CFast interface for storage applications and does not
require a driver.
Notes
For more information about this or other Advantech
products, visit our website at
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service, visit
http://www.advantech.com.tw/eservice
This manual is for PCM-23C1CF
Part No: 200323C101
1 Startup Manual
Pin Assignment
The pin assignments for one of the I/O module
connectors are shown in the tables and figures below.
Description of Pin Use — CN2, CFast Connector
Pin Assignment — Internal Connection
I/O Board CN1 — SATA HDD Cable
PINS1
PINS2
PINS3
PINS4
PINS5
PINS6
PINS7
PINP1
PINP2
PINP3
PINP4
Edition 2
September 2017
GND
PINS1
SATA_TX+
PINS2
SATA_TX-
PINS3
GND
PINS4
SATA_RX-
PINS5
SATA_RX+
PINS6
GND
PINS7
NC
PINPC1
GND
PINPC2
NC
PINPC3
NC
PINPC4
NC
PINPC5
Description of Pin Use — CN1
GND
SATA_TX+
SATA_TX-
GND
SATA_RX-
SATA_RX+
GND
3.3 V
3.3 V
3.3 V
GND
NC
PINPC6
GND
PINPC7
NC
PINPC8
NC
PINPC9
NC
PINPC10
NC
PINPC11
NC
PINPC12
3.3 V
PINPC13
3.3 V
PINPC14
GND
PINPC15
GND
PINPC16
NC
PINPC17
GND
PINP5
GND
PINP6
5 V
PINP7
5 V
PINP8
5 V
PINP9
GND
PINP10
NC
PINP11
GND
PINP12
NC
PINP13
NC
PINP14
NC
PINP15
