- Page 1 Assembly Instructions W02L3107N Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
- Page 4 x 28 x 54 x 54 Cam lock Cam bolt Wooden dowel Ø12x9.5mm Ø6x27.5mm Ø8x30mm x 48 x 18 Screw Screw bolt M6x20mm Ø3.5x12mm Ø4x35mm Drawer slider Adjustable foot Footpads Ø12x9mm 25x25mm Tools Required (Not included)
- Page 5 Step 1 Step 2 Slider arm Slider bracket · Separate the slide bracket from the slide arm as per diagram.
- Page 6 x 28 · Screw cam bolts (A) into panels (4,5,6,7,8,10).
- Page 7 · Attach panels (11) to panels (8,10) with bolts (F) correctly.
- Page 8 · Insert dowels (B) into panels (8,10). · Attach panels (4,5) to panel (8). · Attach panels (6,7) to panel (10). · Insert and secure cam locks (C) to panels (8,10) to lock it. · Stick the skid pads (H) on the bottom of the Wooden leg (4,5,6,7).
- Page 9 Mounting holes x 12 · Attach Slider arms to panel (8,10) with screws (D) correctly.
- Page 10 Mounting holes Mounting holes 180° x 12 · Attach Slider arms to panel (9) with screws (D) correctly.
- Page 11 · screws parts (G) into panels (12). · Insert dowels (B) into panels (12). · Attach panels (2) to panels (12) with screws (E).
- Page 12 x 26 · Screw cam bolts (A) into panels (1,2,3,15,20,24,25).
- Page 13 2 Person Task · Insert dowels (B) into panel (9). · Attach panel (9) to parts (2). · Insert and secure cam locks (C) to panel (9) to lock it.
- Page 14 2 Person Task · Insert dowels (B) into panel (9). · Attach panels (3) to part (9). · Insert and secure cam locks (C) to panel (9) to lock it.
- Page 15 · Attach panels (13,14) to part (5). · Insert and secure cam locks (C) to panels (13,14) to lock it.
- Page 16 2 Person Task · Insert dowels (B) into panels (3). · Attach panels (2,3) to part (8). · Insert and secure cam locks (C) to panels (2,3) to lock it.
- Page 17 2 Person Task x 10 · Insert dowels (B) into panels (3). · Attach panels (2,3,13,14) to part (10). · Insert and secure cam locks (C) to panels (2,3,13,14) to lock it.
- Page 18 · Insert dowels (B) into panels (8,9,10). · Attach panel (1) to panels (8,9,10). · Insert and secure cam locks (C) to panels (8,9,10) to lock it. · Adjust parts (G) to level the unit.
- Page 19 ×2 · Attach panels (16,17) to panel (18) with screws (E). x 16 · Attach panels (21,22) to panel (23) with screws (E). · Carefully slide panel (19) into place along the bottom of the assembly.
- Page 20 · Attach panels (15,24) to panels (16,17). x 16 · Insert and secure cam locks (C) to panels (16,17) to lock it. · Attach panels (20,25) to panels (21,22). · Insert and secure cam locks (C) to panels (21,22) to lock it.
- Page 21 Mounting holes x 24 · Attach slider brackets to panels (16,17,21,22) with screws (D) correctly.
- Page 22 Slider arm Slider bracket Adjust Height / 高さを調節 · Assembled the drawers as per diagram Note : If the drawer does not go in smoothly. Press or lift the plastic release lever. Pull out the slider bracket from the slider arm. Loosen the screws (D) on slider brackets, You can adjust up or down by a few mm.
-
Page 23: Final Assembly
Final Assembly...
