  • Page 1 Assembly Instructions W02F2121W...
  • Page 5 ● The provided glue(F) is to secure wood dowels(A) in place . When first inserting dowels, locate the appropriate hole for the Wooden dowel Cam bolt Cam lock Sticker dowel , place a small amount of glue in the Ø8x30mm Ø15x9mm Ø6x35mm hole and insert the dowel .
  • Page 6 · Insert dowels (A) into panels (6,7). · Attach panels (6,7) to panel (2) with screws (E).
  • Page 7 x 14 · Screw Cam bolts (B) into panels (8,9,10,11,12).
  • Page 8 · Insert dowels (A) into panel (2). · Attach panels (8,10) to panels (2,6,7). · Insert and secure cam locks (C) to panels (2,6,7) to lock it. · Attach panel (9) to panel (2), then insert and secure cam locks (C) to panel (2) to lock it.
  • Page 9 x 12 · Screw Cam bolts (B) into panels (4,5).
  • Page 10 · Insert dowels (A) into panels (5). · Attach panels (4) to panels (5). · Insert and secure cam locks (C) to panels (5) to lock it.
  • Page 11 · Insert dowels (A) into panel (2). · Attach panels (5) to panel (2) correctly. · Insert and secure cam locks (C) to panel (2) to lock it.
  • Page 12 · Insert dowels (A) into panels (4,5). · Attach panel (3) to panels (4,5) with screws (E).
  • Page 13 · DO NOT Tighten the bolts to ensure the assembly successfully in this step. x 16 · Attach parts (20) to parts (18,19) with Bolts (G).
  • Page 14 Step 2 Step 1 · Attach parts(18,19) to panel(3) with Bolts(G). · Then tighten all bolts to secure the unit in this assembly step.
  • Page 15 x 14 · Screw Cam bolts (B) into panel (1). · Attach part (21) to panel (1) with bolts (N).
  • Page 16 · Attach Handle (J) to panel (9) with bolts (I). x 16 x 14 · Insert dowels (A) into panels (4,5,6,7,8,9,10). · Attach panel (1) to panels (4,5,6,7,8,9,10). · Insert and secure cam locks (C) to panels (5,6,7,8,9,10) to lock it.
  • Page 17 · Insert dowels (A) into panel (2). · Attach panels (11,12) to panels (2,6,7). · Insert and secure cam locks (C) to panels (2,6,7) to lock it.
  • Page 18 Slider arm Slider arm Slider bracket Slider bracket · Separate the slider bracket from the slider arm as per diagram. · Attach slider arms to panels (6,7) with screws (K) correctly.
  • Page 19 · Attach panels (14,15) to panel (16) with screws (L). · Carefully slide panel (17) into place along the bottom of the assembly.
  • Page 20 · Screw Cam bolts (B) into panel (13). · Attach Handle (J) to panel (13) with bolts (I). · Attach panel (13) to panels (14,15). · Insert and secure cam locks(C) to panels (14,15) to lock it.
  • Page 21 · Attach slider brackets to panels (14,15) with screws (K) correctly.

  • Page 22: Final Assembly

    · Stick stickers(D) on cam locks(C). x 44 Slider arm Slider bracket · Assembled the drawers as per diagram Note :If the drawer does not go in smoothly. Press or lift the plastic release lever. Pull out the slider bracket from the slider arm then re-assembled the drawer until they were going in smoothly well.
