PEL-3000AH Assembly Guide This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
Page 3
11EL-00900101 1 Bus Bar Connector (Included PEL-005) GRA-413-E 01RA413E000T 4 PEL-3111 3U Frame (Optional) GRA-414-E 01RA414E000T 1 PEL-3111 3U Frame (Optional) Note Refer to the PEL-3000AH Series Rack Parts details_EN.doc for the other models. Front View Rear View Final Assemble Result...
Page 4
PEL-3000AH Series Parallel Assembly Guide Rear View with Isolated ventilation door Isolated ventilation door Note It is highly recommended to install the isolated of vent door on the back.
Page 5
PEL-3000AH Series Parallel Assembly Guide SSEMBLE PROCEDURE Put the 1st PEL-3211AH on the bottom of the rack followed by fastening Step 1 the 4 screws for side bracket in the front but not tightening them completely. Screw the L-shape brackets in the interior side of rack. An approx. 1mm...
Page 6
PEL-3000AH Series Parallel Assembly Guide Put the 2nd PEL-3211AH onto the L-shape brackets within the rack and, Step 3 again, fasten the 4 screws for side bracket in the front but not tighten them fully followed by screwing another group of L-shape brackets within the interior of rack.
Page 7
PEL-3000AH Series Parallel Assembly Guide OPPER TICK SSEMBLY Assemble the L-type copper stick (PEL-005) onto the output terminal in Step 1 the rear side of each unit as the figure below shown. L-type copper stick assembly L-type copper sticks assembly completion...
Page 8
PEL-3000AH Series Parallel Assembly Guide ARALLEL CABLES INSTALLATION Install the parallel cables in accord with the following figure. Step 1 The last cable connecting to the last unit cannot be clipped with core. When Note only one PEL-3111AH connects to a PEL-3211AH (Booster) in parallel, the...
Page 9
PEL-3000AH Series Parallel Assembly Guide ONNECT TO POWER CORD Refer to the figure below; connect the AC power cords for all units to the Step 1 power sockets in the rear side individually followed by powering on the power switch that is underneath the power socket (─ indicates power ON).
Page 10
PEL-3000AH Series Parallel Assembly Guide YSTEM IN SERIAL SETTING Power on the power switch in the Master front panel and the indicator Step 1 lights up in green as figure below shown: The master will automatically detect the number of Boosters connected in Step 2 parallel.
Page 11
PEL-3000AH Series Parallel Assembly Guide URRENT SINK CURRENT DIVISION CHECKUP The current sink power of PEL-3111AH and PEL-3211AH is 1KW:2KW; Description therefore, the ratio of current sink will always be the exactly 1:2. E.g., PEL-3322AH (3KW); when current sink is set 30A, Master (PEL-3111AH) will sink current by 10A, whilst Booster (PEL-3211AH) will sink current by 20A.
Page 12
PEL-3000AH Series Parallel Assembly Guide Power ON PEL-3211AH Power ON PEL-3211AH Power OFF Power OFF PEL-3211AH Power OFF PEL-3211AH Power Supply Power OFF PEL-3211AH The 2nd Booster current checkup: Step 3 I. Connect the parallel cable to the J2 connector in the rear of PEL-3111H in one end and the J1 connector in the rear of PEL-3211H in the other end.
Page 13
PEL-3000AH Series Parallel Assembly Guide Power ON PEL-3211AH Power OFF PEL-3211AH Power ON PEL-3211AH Power OFF PEL-3211AH Power Supply Power OFF PEL-3211AH Follow the previous steps to validate the 3rd and the 4th Booster Step 4 respectively. The assembly procedure and system setting are completely finished.
