  • Page 1 QUICK START GUIDE PSU Series ISO-9001 CERTIFIED MANUFACTURER...
  • Page 2 This quick start guide contains proprietary information, which is protected by copyright. All rights are reserved. No part of this quick start guide may be photocopied, reproduced or translated to another language without prior written consent. The information in this quick start guide was correct at the time of printing. However we continue to improve our products and therefore reserve the right to change the specifications, equipment, and maintenance procedures at any time without notice.

  • Page 3: Afety Instructions

    AFETY INSTRUCTIONS Safety Symbols These safety symbols may appear in the user manual or on the instrument. Warning: Identifies conditions or practices that could result Warning in injury or loss of life. Caution: Identifies conditions or practices that could result Caution in damage to the instrument or to other properties.

  • Page 4: Etting Started

    ETTING STARTED Main Features Performance • High power density: 1500W in 1U • Universal input voltage 85~265Vac, continuous operation. • Active power factor correction. Features • Parallel master/slave operation with active current sharing. • Remote sensing to compensate for voltage drop in load leads.

  • Page 5: Front Panel Overview

    Appearance Front Panel Overview Display Area Voltage Current DC Power Supply 0 - 40 V / 0 - 38A PSU 40-38 VOLTAGE CURRENT Lock/ Local PROT Function Test Shift Output : Long Push Unlock ALM_CLR 9 10 12 13 Description 1.

  • Page 6: Rear Panel Overview

    Rear Panel Overview ISOLATED PROGRAMMING 4 – 20mA ISOLATED PROGRAMMING 0 – 5V / 0 – 10V 6-60V models: PSU 6-200, 8-180, 12.5-120, 15-100, 20-76, 30-50, 40-38, 50-30, 60-25 DC OUTPUT RS485 / 232 ANALOG PROGRAMMING 240V S LS 47 63Hz 2000VA MAX.

  • Page 7: Power Down

    ET UP Power Up 1. Connect the power cord to the socket on the rear panel. 2. Turn on the power switch on the front panel. 3. The power supply will show the Power On settings (Pon) at start up. If no Power On settings are configured, the PSU will recover the state right before the power was last turned OFF.

  • Page 8: How To Use The Instrument

    How to Use the Instrument Background The PSU power supplies use a novel method of configuring parameter values only using the voltage or current knobs. The knobs are used to quickly edit parameter values at 0.01, 0.1 or 1 unit steps at a time. When the user manual says to set a value or parameter, use the steps below.
  • Page 9 PECIFICATIONS The specifications apply when the PS U is powered on for at least 30 minutes. Output Model PS U 30-50 80-19 Rated Output Voltage Rated Output Current Rated Output Power 1500 1520 Constant Voltage Mode 30-50 80-19 Model Line regulation Load regulation Ripple and noise r.m.s.
  • Page 10 Constant Current Mode Model 30-50 80-19 Line regulation Load regulation Ripple and noise r.m.s. Temperature ppm/°C 100ppm/°C of rated output current, after a coefficient 30 minute warm-up. Protection Function Model 30-50 80-19 Setting range 3 - 33 5 - 88 Over voltage protection Setting...
  • Page 11 General Specifications 30-50 80-19 Model Weight Less than 8.7kg(main unit only) Dimensions (W×H×D) 423mm×43.6mm×447.2mm Cooling Forced air cooling by internal fan. Complies with the European EMC directive for Class A test and measurement products. Complies with the European Low Voltage Directive and carries the Safety CE-marking.
  • Page 12 Notes: Minimum voltage is guaranteed to maximum 0.2% of the rated output voltage. Minimum current is guaranteed to maximum 0.4% of the rated output current. At 85 ~ 132Vac or 170 ~ 265Vac, constant load. From No-load to Full-load, constant input voltage. Measured at the sensing point in Remote Sense.

  • Page 13: Eclaration Of Conformity

    eclaration of Conformity GOOD WILL INSTRUMENT CO., LTD. declare that the below mentioned product satisfies all the technical relations application to the product within the scope of council: Directive: EMC; LVD; WEEE; RoHS The product is in conformity with the following standards or other normative documents ◎...

This manual is also suitable for:

Psu 80-19Psu 100-15Psu 150-10Psu 300-5Psu 400-3.8Psu 600-2.6
