- Page 1 DC Electronic Load PEL-3000A(H) Series QUICK START GUIDE GW INSTEK PART NO. 82EL-3111AM01 ISO-9001 CERTIFIED MANUFACTURER...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.
-
Page 3: Afety Instructions
AFETY INSTRUCTIONS This section contains the basic safety symbols that may appear on the accompanying User Manual CD or on the instrument. For detailed safety instructions and precautions, please see the Safety Instructions chapter in the user manual CD. Safety Symbols These safety symbols may appear in the user manual or on the instrument. - Page 4 Power Cord for the United Kingdom When using the instrument in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow: Earth...
-
Page 5: Etting Started
ETTING STARTED The Getting Started chapter introduces the instrument’s main features, appearance, and set up procedure. Overview The PEL-3000A(H) Series is a family of high performance DC electronic loads positioned to test a wide range of different power sources. The DC electronic loads are fully programmable to simulate anything from basic static loads to complex dynamic loads. - Page 6 • High capacity when used in parallel: 5250W, 1050A(262.5A), PEL-3111A(H) x 5) 9450W, 1890A(472.5A), PEL-3111A(H) +PEL-3211A(H) x 4) • High resolution – 16 bit • 7 operating modes: CC, CV, CR, Features CP, CC+CV, CR+CV, CP+CV • Independent and parallel operation •...
- Page 7 Package Contents and Accessories Standard Accessories Item Part Number User /Programming Manual CD Quick Start Guide (this document) Load input terminal Cover, M3 PEL-011 screw x1 Terminal fittings: 2 sets of PEL-012 bolts/nuts/springs/washers (type: M8), terminal cover x1 (for PEL- 3000AH series only), monitor out cover x 1 (for PEL-3021AH, PEL- 3041AH, PEL-3111AH only)
- Page 8 Rack mount frame for PEL- GRA-414-E 3021A(H), PEL-3041A(H), PEL- 3111A(H)/EIA Rack mount frame for PEL- GRA-414-J 3021A(H), PEL-3041A(H), PEL- 3111A(H)/JIS GPIB cable, 2.0m GTL-248 USB cable. Type A - Type B GTL-246 Dust filter PEL-010 CR123A 3V lithium battery for 3813-030D0501 clock.
-
Page 9: Front Panel
Front Panel PEL-3021A and PEL-3041A Local Main File FUNC Utility Help Short Load Preset Shift CAL. Lock Clear Enter 175W 1.5 - 150V 0 - 35A I MON OUT TRIG OUT PEL-3021AH and PEL-3041AH Local Main File FUNC Utility Help Short Load A/ B... - Page 10 10. Scroll wheel 11. Number pad, Clear/ 12. USB port, Preset and Lock and Enter keys Shift keys 13. I MON OUT and TRIG 14. Input terminals OUT(for PEL-3000A series) I MON OUT, V MON OUT, TRIG OUT(for PEL-3000AH series)
-
Page 11: Rear Panel
Rear Panel PEL-3021A and PEL-3041A PEL-3021AH and PEL-3041AH V/I MON OUT FRAME CONT RS232/ RS485 GPIB 100 - 120 VAC 200 - 240 VAC 47 - 63 Hz DEVICE... -
Page 12: Variable Resistor
PEL-3111A FRAME CONT DC INPUT 1050 W 1.5 V - 150 V , 210 A RS232/ RS485 100 - 120 VAC 200 - 240 VAC 47 - 63 Hz 190 VA MAX. GPIB DEVICE PEL-3111AH V/I MON OUT FRAME CONT DC INPUT 1050 W 5 V - 800 V , 52.5 A RS232/... -
Page 13: Display Overview
Display Overview RS232 LOAD 03/Sep/2012 0.000 0.00 0.000 CC A Value 0.000 CC B Value 0.000 Fine SlewRate 2500.00 mA/us A Value Mode I Range V Range Function Configure H 35A L 15V Static Description 1. Date and time 2. Main frame status panel 3. - Page 14 3. If the unit doesn’t turn on, press the ON/STBY key on the front panel. The ON/STBY key will go from standby (red) to ON (green). 4. The unit will show the splash screen and then load the settings from when the unit was last powered down.
- Page 15 Updating the Firmware The PEL-3000A(H) allows the firmware to be updated by end-users. Before using the PEL-3000A(H), please check the GW Instek website or ask your local distributor for the latest firmware. Before updating the firmware, please check the firmware version.
- Page 16 Do not turn the load generator off or Warning remove the USB memory when the firmware is being read or upgraded. Conventions The following conventions are used throughout the user manual. Read the conventions below for a basic grasp of how to operate the PEL-3000A(H) menu system using the front panel keys.
-
Page 17: Parameter Input
Toggle Parameter or State Function/Item Mode Parameter or State This type of soft-menu icon has the function/item on the top of the label and the selected setting or mode on the bottom of the label. Repeatedly press the associated function key (F1~F5) to cycle through each setting. - Page 18 RS232 LOAD 03/Sep/2012 0.000 0.00 0.000 Parameter CC A Value 0.000 CC B Value 1.000 Fine SlewRate 2500.00 mA/us A Value Mode I Range V Range Function Configure H 35A L 15V Static 4. Press the Enter key again to finish editing the parameter value.
- Page 19 Entering Alphanumeric Characters When renaming files, creating memos or notes, you will be required to enter alphanumeric characters when the character entry screen appears. Only alphanumeric characters as well as space [ ], underscore [_] and minus [-] characters are allowed. 1.
- Page 20 EL-3000A SPECIFICATIONS The following are the basic specifications for the PEL- 3000A series. For detailed specifications, please see the user manual Rating Model PEL-3021A PEL-3041A PEL-3111A Voltage 0V~150V Current 210A Min. Operating 1.5V at 35A 1.5V at 70A 1.5V at 210A Voltage Power 175W...
- Page 21 CP Mode Operating Range Model PEL-3021A PEL-3041A PEL-3111A H Range 17.5W ~175W 35W~350W 105W ~1050W M Range 1.75W ~17.5W 3.5W~35W 10.5W ~105W L Range 0.175W~1.75W 0.35W~3.5W 1.05W ~10.5W Slew Rate CC Mode Setting Range Model PEL-3021A PEL-3041A PEL-3111A H Range 2.5mA/μs~ 16.02mA/μs~ 5mA/μs~5A/μs 2.5A/μs...
- Page 22 EL-3000AH SPECIFICATIONS The following are the basic specifications for the PEL- 3000AH series. For detailed specifications, please see the user manual Rating Model PEL-3021AH PEL-3041AH PEL-3111AH Voltage 0V/800V Current 8.75A 17.5A 52.5A Min. Operating 5V at 8.75A 5V at 17.5A 5V at 52.5A Voltage Power...
- Page 23 CP Mode Operating Range Model PEL-3021AH PEL-3041AH PEL-3111AH H Range 17.5W ~175W 35W~350W 105W ~1050W M Range 1.75W ~17.5W 3.5W~35W 10.5W ~105W L Range 0.175W~1.75W 0.35W~3.5W 1.05W ~10.5W Slew Rate CC Mode Setting Range Model PEL-3021AH PEL-3041AH PEL-3111AH H Range 0.1400mA/μs~ 0.280mA/μs~ 0.840mA/μs~84 140.0mA/μs...
-
Page 24: Certificate Of Compliance
Certificate Of Compliance GOOD WILL INSTRUMENT CO., LTD. declare that the CE marking mentioned product satisfies all the technical relations application to the product within the scope of council: Directive: EMC; LVD; WEEE; RoHS The product is in conformity with the following standards or other normative documents: ◎...
