- Page 1 Multi-Range DC Power Supply PSB-1000 Series QUICK START GUIDE GW INSTEK PART NO. 82SB-18000M01 ISO-9001 CERTIFIED MANUFACTURER...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.
-
Page 3: Afety Instructions
AFETY INSTRUCTIONS This section contains the basic safety symbols that may appear on the accompanying User Manual CD or on the instrument. For detailed safety instructions and precautions, please see the Safety Instructions chapter in the user manual CD. Safety Symbols These safety symbols may appear in the user manual or on the instrument. - Page 4 Power Cord for the United Kingdom When using the instrument in the United Kingdom, make sure the power cord meets the following safety instructions. NOTE: This lead/appliance must only be wired by competent persons. WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in this lead are coloured in accordance with the following code: Green/ Yellow: Earth...
-
Page 5: Etting Started
Overview The PSB-1000 Series consists of 4 models: PSB-1400L, PSB-1400M, PSB-1800L, and PSB-1800M. Note that throughout the user manual, the term “PSB-1000” refers to all the models in the PSB-1000 Series lineup, unless stated otherwise. - Page 6 OVP, OCP and OTP protection • Features Low AC input protection • Sequence function • Large 3.5 inch LCD panel • 100V - 240V power inlet • Multi-range output power • Bleeder circuit ON/OFF setting • CV, CC priority start function •...
- Page 7 Basic Accessory Kit: PSB-106 M4 terminal screws and washers x2, M8 terminal bolts, nuts and washers x2, Analog control protection dummy x1, analog control lock level x2, short bar x1. Optional Accessories Item Part Number Analog remote control connector kit: PSW-001 Socket x 1pc Pins x 10pcs...
-
Page 8: Front Panel
Front Panel Local Multi-Range DC Power Supply PSB-1400M 0 - 160V / 0 - 10A , 400W Main Utility File FUNC Voltage Current CLR PROT. Unlock Enter Lock : Long Push Clear Output 0 - 160V , 10A Description F1~F5 soft-keys... -
Page 9: Line Input
TRIG IN GPIB TRIG OUT VOLT TRIG 240V 47 63Hz 550VA MAX. SER. NO. LB Description TRIG OUT TRIG IN Rear panel terminals 4. J1connector USB B port GPIB option Line input x1: PSB-1800M/L x2: PSB-1400M/L LAN port 10. VOLT TRIG... -
Page 10: Status Bar
Status Bar Icons Status bar Description Output OFF OVP tripped CV mode active OCP tripped CC mode active OTP tripped Output operating Remote sense fail at 105% rated Power fail power (CP mode) Speaker enabled GPIB installed Speaker disabled GPIB installed & disabled Panel lock on Connected to PC... -
Page 11: First Time Use Instructions
First Time Use Instructions Use the following procedures when first using the PSB-1000 to power up the instrument, reset to the factory settings, view the system information and install the USB driver. Lastly, the How to Use the Instrument section will introduce you to the basic operating conventions used throughout the user manual. - Page 12 Reset to Factory Settings The factory default settings can be restored from the Utility menu. See the user manual for a list of factory settings. Utility Press the key. The utility menu will appear on the display. Go to Factory Setting and press Enter. Press Restore[F4] to restore the factory settings.
- Page 13 USB Driver Installation If the USB Type B interface is to be used for remote control, the USB driver needs to be installed. The USB driver, GW_PSB1k, is located Note on the CD-ROM that accompanied this user manual. Alternatively the driver can be downloaded from the GW Instek website.
-
Page 14: How To Use The Instrument
The soft-menu keys have a number of different functions, depending on the use-case. They can be used as quick-action keys, option keys or as submenus. Local Multi-Range DC Power Supply PSB-1400M 0 - 160V / 0 - 10A , 400W Main FUNC Utility File... - Page 15 Selecting Menu Items Turn the scroll wheel to select parameters in menus and lists. The selected parameter will be highlighted in orange. The scroll wheel is also used to increment/decrement setting values. Press the Enter key to edit the Enter parameter or to enter the selected menu.
- Page 16 Using the Keypad to edit parameter values When editing a value the keypad can be used to directly enter the desired value. Type the value of the parameter using the keypad. Clear Press the Enter key to confirm the Enter edit.
- Page 17 Cursor Repeat the steps above for all the relevant digits. Press the Enter key to confirm the Enter edit. Using the onscreen keyboard The onscreen keyboard is used for creating filenames, renaming files, and so on. The screenshot below is an example of the onscreen keyboard.
- Page 18 PECIFICATIONS The following are the basic specifications for the PSB- 1000. For detailed specifications, please see the user manual. Output (400W models) Model PSB-1400L PSB-1400M Rated output 160V voltage* Rated output current* Rated output power 400W 400W Power Ratio...
- Page 19 Constant Current Mode (400W models) Model PSB-1400L PSB-1400M Line regulation* 45mA 15mA Load regulation* 45mA 15mA Ripple and noise* 80mA 20mA Output (800W models) Model PSB-1800L PSB-1800M Rated output 160V voltage* Rated output current* Rated output power 800W 800W Power Ratio...
-
Page 20: Declaration Of Conformity
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD. No. 69, Lushan Road, Suzhou New District Jiangsu, China declare that the below mentioned products PSB-1400L, PSB-1400M, PSB-1800L, PSB-1800M are herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to the Low Voltage Directive (2004/108/EC &...
