3 ROUTINE UTILIZATION AND MEASUREMENT 30
The LOT number, target values (range) and parameter of the uploaded controls are shown in one line. Note
that each level of the control is displayed in a separate line.
The column Result shows the last recorded value, and date and time information are available in the column
Date Time.
The flag in the column Range shows a P for passed if the result matches the target value. If the flag in the
column Range is in red and shows a CH or CL, the result of the control was too high (CH) or too low (CL).
To delete a control because it has expired or for other reasons, press the dark grey button in front of the
control to be deleted.
An hourglass is shown if a control is currently running in Auto mode and stays in the analyser for incubation
and reading. The number next to the hourglass indicates the remaining incubation time in mm:ss.
The latest result of a control reading is shown in the last line.
Note: To delete a control result, press the dark-grey button on each listed control result.

3.3.1 Upload of new control material

The control kits contain a target value sheet that provides the range which the parameters must match, and
a LOT number.
Figure 3-7 Upload of control data from target value sheet
To upload all data (LOT, level, target values) of a control, the target value sheet of the control is needed.
First, press Card name. This opens the next window for selection of
a control parameter, like PCT in this example.
Select the level of the control.
Type in the LOT number.
Select the Expiration date.
Type in the target value (according to the units of parameter).
To complete the upload of new controls, press the Add button.
