Triangulation sensor (BGS)
Dimensions
M3 (2x)
11
3.3

Technical Data

General specifications
Detection range
Detection range min.
Detection range max.
Adjustment range
Reference target
Light source
Light type
LED risk group labelling
Black-white difference (6 %/90 %)
Diameter of the light spot
Opening angle
Ambient light limit
Functional safety related parameters
MTTF
d
Mission Time (T )
M
Diagnostic Coverage (DC)
Indicators/operating means
Operation indicator
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: +1 330 486 0001
www.pepperl-fuchs.com fa-info@us.pepperl-fuchs.com
21.5
8.7
14.5
3.2
5 ... 350 mm
5 ... 25 mm
5 ... 350 mm
25 ... 350 mm
standard white, 100 mm x 100 mm
LED
modulated visible red light
exempt group
< 15 % at 350 mm
approx. 20 mm at a distance of 350 mm
approx. 3 °
EN 60947-5-2 : 40000 Lux
600 a
20 a
0 %
LED green:
constantly on - power on
flashing (4Hz) - short circuit
flashing with short break (1 Hz) - IO-Link mode
Germany: +49 621 776 1111
fa-info@de.pepperl-fuchs.com
Receiver
Emitter
Singapore: +65 6779 9091
fa-info@sg.pepperl-fuchs.com
OBT350-R100-2EP-IO
2
