Pepperl+Fuchs OBT350-R100-2EP-IO Manual page 3

Triangulation sensor (BGS)
Technical Data
Function indicator
Control elements
Control elements
Electrical specifications
Operating voltage
Ripple
No-load supply current
Protection class
Interface
Interface type
IO-Link revision
Device profile
Device ID
Transfer rate
Min. cycle time
Process data width
SIO mode support
Compatible master port type
Output
Switching type
Signal output
Switching voltage
Switching current
Usage category
Voltage drop
Switching frequency
Response time
Conformity
Communication interface
Product standard
Approvals and certificates
UL approval
Ambient conditions
Ambient temperature
Storage temperature
Mechanical specifications
Housing width
Housing height
Housing depth
Degree of protection
Connection
Material
Housing
Optical face
Mass
Cable length
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: +1 330 486 0001
www.pepperl-fuchs.com fa-info@us.pepperl-fuchs.com
LED yellow:
constantly on - object detected
constantly off - object not detected
Light-on/dark-on changeover switch
Sensing range adjuster
U 10 ... 30 V DC
B
max. 10 %
I < 25 mA at 24 V supply voltage
0
III
IO-Link ( via C/Q = BK )
1.1
Smart Sensor
0x110601 (1115649)
COM2 (38.4 kBit/s)
2.3 ms
Process data input 1 Bit
Process data output 2 Bit
yes
A
The switching type of the sensor is adjustable. The default setting is:
C/Q - BK: NPN normally open / light-on, PNP normally closed / dark-on, IO-Link
/Q - WH: NPN normally closed / dark-on, PNP normally open / light-on
2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected,
overvoltage protected
max. 30 V DC
max. 100 mA , resistive load
DC-12 and DC-13
U ≤ 1.5 V DC
d
f 500 Hz
1 ms
IEC 61131-9
EN 60947-5-2
E87056 , cULus Listed , class 2 power supply , type rating 1
-40 ... 60 °C (-40 ... 140 °F) , fixed cable
-25 ... 60 °C (-13 ... 140 °F) , movable cable not appropriate for conveyor chains
-40 ... 70 °C (-40 ... 158 °F)
11 mm
37.1 mm
21.5 mm
IP67 / IP69 / IP69K
2 m fixed cable
PC (Polycarbonate)
PMMA
approx. 36 g
2 m
Germany: +49 621 776 1111 Singapore: +65 6779 9091
fa-info@de.pepperl-fuchs.com fa-info@sg.pepperl-fuchs.com
OBT350-R100-2EP-IO
3
