  • Page 1 Matrixx Greensand Plus Iron Filtration System 081-MXF-GS-XXX...

  • Page 2: Table Of Contents

    Table of Contents Unpacking and Inspection ..................3 Safety Guide ...................... 3 Before Starting Installation ..................4 Proper Installation ....................4 Tools, Pipe, Fittings, and Other Materials ............4 System Dimensions ....................5 Backwashing Filter Introduction ................6 Where to Install the System ..................7 Water Meter Installation Instructions .................

  • Page 3: Unpacking And Inspection

    Be sure to check the entire unit for any shipping damage or lost parts. Also note damage to the shipping cartons. Contact US Water Systems at 1-800-608-8792 to report any shipping damage within 24 hours of delivery. Claims made after 24 hours may not be honored.

  • Page 4: Before Starting Installation

    Before Starting Installation Proper Installation This water treatment system must be properly installed and located in accordance with the Installation Instructions before it is used or the warranty will be void. • Do not Install or store where it will be •...

  • Page 5: System Dimensions

    System Dimensions Model Tank Size MXF-GS-150 10" x 54" 61.00" 55.25" 10" MXF-GS-200 12" x 52" 59.00" 53.25" 12" MXF-GS-250 13" x 54" 61.00" 55.25" 13" MXF-GS-300 14" x 65" 71.00" 66.25" 14" Need help? 1.800.390.5936 www.uswatersystems.com...

  • Page 6: Backwashing Filter Introduction

    Backwashing Filter Introduction The Matrixx Greensand Plus Iron Filter system is designed to remove iron and manga- nese from the water using chlorine as an oxidizer. Once a residual chlorine is produced following the system, the iron is removed. Chlorine is injected in the feed water line to oxidize the iron then the water goes in to a high speed retention / reaction tank to com- plete the reaction.

  • Page 7: Where To Install The System

    Where to Install the System • Place the system as close as possible to develops. The manufacturer will not re- the pressure tank (well system) or water pair or pay for water damage. meter (city water). • A 120 volt electric outlet is needed within •...

  • Page 8: Water Meter Installation Instructions

    Water Meter Installation Instructions Install the water meter. There is a flow direction arrow on the meter. Be sure the inlet plumbing is attached to the meter correctly. Slide the nut over the connection nipple, apply Teflon tape and install it in the inlet plumbing.
  • Page 9 Install the rubber washer gasket in the connecting nut and install the water meter with the flow arrow pointing away from the inlet fitting. Tighten the nut hand tight. An adjustable wrench can be used to tighten the nut an additional 1/4 to 1/2 turn. The rubber washer gasket will seal the connection so the nut should not be over tightened.
  • Page 10 Slide the nut over the outlet nipple and install the outlet nipple in the outlet plumbing. Use Teflon tape to seal the connection and tighten with an adjustable wrench. Do not over tighten the nipple in the outlet plumbing connection or damage could occur. Install the rubber washer gasket in the nut and tighten the outlet plumbing to the water meter outlet connection.

  • Page 11: Chemical Solution Tank (With Pump) Installation Instructions

    Chemical Solution Tank (With Pump) Installation Instructions Install the chemical pump mounting bracket on the solution tank. Center the bracket on the back side of the tank. Install two #10 x 3/4" screws in the outer holes. Tighten all screws. Install the chemical injection pump on the bracket that was installed on the tank using the screws taped to the bracket.
  • Page 12 Drill a 1/4" hole in the top of the solution tank and install the tubing into the tank. Install the weighted suction screen on the tubing that was inserted in the tank. Push the tubing down in the tank until the weighted suction screen is around 1" from the bottom of the tank.
  • Page 13 Install the other end of the tank suction tube to the chemical injection pump inlet. The inlet is identified by an arrow pointing toward the pump. Be sure the sleeve is installed on the tubing properly. The beveled side of the sleeve should be facing the pump.

  • Page 14: Chemical Pump Wiring Installation Instructions

    Install a piece of tubing on the outlet of the pump. Be sure to orient the sleeve properly and hand tighten the nut. The outlet is identified by an arrow that is pointing away from the pump. The other end of the outlet tube from the chemical pump will be installed in the injection check valve (installed next).
  • Page 15 The wire coming from the chemical injection pump will have several colors. Fold back all wires but the red and black wire. Make sure the wires that are folded back are not touching each other or anything else. Tape the wires back. Now connect the black wires together with a wire nut or butt splice connector.

  • Page 16: Retention Tank Installation

    Retention Tank Installation Remove the retention tank from the packaging. Install the drain fitting and valve on the bottom. Be sure to use Teflon tape when installing the valve. Install the nut, O-ring and retaining clip on the supplied gray elbow fitting. Grease the O-ring with food grade silicone grease.

  • Page 17: Preparation

    Preparation Filter Tank Preparation Water Pressure: A minimum of 30 pounds of water pressure is required for the regenera- tion valve to operate effectively. Electrical Facilities: An uninterrupted alternating current (AC) supply is required. Note: Other voltages are available. Please make sure your voltage supply is compatible with your unit before installation.
  • Page 18 Use the funnel provided to pour the media into the tank. The order the media is pour- ed in is important. Begin by pouring the Quartz Gravel into the bottom of the tank. Pour it evenly around the hole to ensure it is well distributed in the tank and pour slow enough to keep from plugging the hole.
  • Page 19 Install the upper basket on the bottom of the valve by lining up the tabs then turning the basket clockwise to lock it in place. Place the upper basket over the distributor tube and push the valve onto the tank. Thread the valve on the tank by turning it clockwise.
  • Page 20 Tighten the valve hand tight then snug it further by tapping it with the palm of the hand. DO NOT use tools to tighten the valve or damage could occur. Need help? 1.800.390.5936 www.uswatersystems.com...

  • Page 21: Installation Instructions

    Installation Instructions If your hot water tank is electric, turn off the power to it to avoid damage to the element in the tank. If you have a private well, turn the power off to the pump and then shut off the main water shut off valve.
  • Page 22 Insert the provided plumbing fittings into the bypass. 3/4" and 1" male pipe thread fittings are supplied so ensure you pick the correct one for your plumbing. Tighten the retaining nuts hand tight, ensuring that the fittings are not cross threaded. Need help? 1.800.390.5936 www.uswatersystems.com...
  • Page 23 Be sure to use Teflon tape or other pipe sealant on the plumbing fitting threads and install them on the bypass accordingly. Use an adjustable wrench to ensure they are tight. NOTE: All piping should be secured to prevent stress on the bypass valve and connectors.
  • Page 24 Connect the drain hose to the valve and secure it with a hose clamp. Run the drain hose to the nearest laundry tub, floor drain or approved air gap fitting. The drain can be ran overhead or down along the floor. Drain tubing should be a minimum of 1/2" ID.

  • Page 25: Chemical Injection Pump Start-Up Instructions

    Chemical Injection Pump Start-up Instructions Proceed to mix the chlorine solution needed for the storage tank. Mix the chlorine in a 5 gallon bucket. Mix one bottle of granular chlorine to 5 gallons of warm water. Then pour the bucket in the holding tank. Make up 10 gallons of solution then trend the usage over the first month.

  • Page 26: System Regeneration

    System Regeneration Normal Operation Home Display - The home display will alternate between the time of day and gallons left until the next regeneration. The meter will count down to zero (0000) and then regenerate at the scheduled time set. Starting a Regeneration Cycle To Start Delayed Extra Cycle •...

  • Page 27: Programming Using Onboard Buttons

    Programming Using Onboard Buttons To enter the Main Menu, press the Menu/Enter button. (Time of Day will flash) To set the Time of Day, press the Set/Change button. (First digit will flash) • To change digit value, press the Set/Change button. •...

  • Page 28: Programming Using Legacy View App

    Programming Using Legacy View App The Legacy View app allows the user to control every aspect of the water system from the convenience of a smart phone. The Legacy View app will allow the user to monitor usage history, change cycle times, start a regeneration and advance through a regenera- tion.
  • Page 29 Dashboard Parameters that can be changed are indicated with orange font. To change a parameter, tap on the orange font then use the keyboard that appears to change the value. Time of Day: Tap on the "Time of Day" box. A box will appear that allows you to set the unit to the time that matches the device being used to program the unit.
  • Page 30 Advanced Settings Parameters that can be changed are indicated with orange font. To change a parameter, tap on the orange font then use the keyboard that appears to change the value. Backwash: This should be set to "10" min and should not be changed. Rest: This should be set to "2"...
  • Page 31 Status and History The Status and History screen shows current conditions of the system as well as flow rate and usage history. There are two parameters that can be reset. Total Regenerations: This parameter shows how many times the system has regen- erated since it was put in service or since the last time the value was reset.

  • Page 32: Automatic Bypass During Regeneration

    Automatic Bypass During Regeneration The regeneration cycle can last 25 to 30 minutes, after which treated water service will be restored. During regeneration, untreated water is automatically bypassed for use in the household. This is why automatic regeneration is set for sometime during the night and manual regenerations should be performed when little or no water will be used in the household.

  • Page 33: System Start Up

    System Start Up With the bypass handles in the bypass position, turn on the main water supply and initiate an immediate regeneration. This will advance the valve to the backwash position. Once the valve has stopped moving and is in the backwash position, slowly open the bypass handles about 1/8th turn.

  • Page 34: Chlorine Injection Setting

    Chlorine Injection Setting To set the chlorine injection rate, open a faucet directly after the system and take a sample. The injection pump should be adjusted so there is about 1 PPM of residual chlorine after the system. Run water for 20 - 25 minutes. Take a sample after the system and test the chlorine level.

  • Page 35: Features

    Features Battery Back-Up (Uses a standard 9-volt alkaline battery.) • During power failures, the battery will maintain the time of day as long as the battery has power. The display is turned off to conserve battery power during this time. To confirm that the battery is working, press either button and the display will turn on for five (5) seconds.
  • Page 36 Pull out the 9V battery connector, remove the battery cover, and attach the battery to the connector. Push the battery back in the holder on the valve and replace the cover and screws. Need help? 1.800.390.5936 www.uswatersystems.com...

  • Page 37: What To Expect

    What to Expect The Matrixx Greensand Plus Iron Filter will produce iron free water immediately after installation. Depending on the raw water quality, there may be contaminants built up in the water heater, plumbing system and other devices. Over the first few weeks, as water is used, there could be traces of this build up that are being removed by the newly installed system.

  • Page 38: Routine Maintenance

    Routine Maintenance • Pressure Tank - If the plumbing system uses a bladder pressure tank, it will be in the system prior to the Greensand system. This tank should be drained periodically to remove any build up of contaminants. Typically once a quarter is sufficient but that frequency may need to be increased on systems with high contaminant levels.

  • Page 39: Power Head Exploded View / Parts List

    Power Head Exploded View / Parts List Need help? 1.800.390.5936 www.uswatersystems.com...

  • Page 40: Bypass Exploded View / Parts List

    Bypass Exploded View / Parts List Need help? 1.800.390.5936 www.uswatersystems.com...

  • Page 41: Valve Body Exploded View / Parts List

    Valve Body Exploded View / Parts List Need help? 1.800.390.5936 www.uswatersystems.com...

  • Page 42: Warranty

    TO PLACE THIS EQUIP- Lifetime Warranty on Greensand Plus Tank MENT UNDER WARRANTY, THE WAR- - US Water Systems will replace the Green- RANTY REGISTRATION MUST BE COM- sand Plus tank of the System, to any origi- PLETED AND RETURNED BY THE ORIG-...
  • Page 43 US Water Systems does not authorize any incurred as a result of a defect or for failure person to assume for us any other obliga- to meet the terms of this limited warranty tion on the sale of this water system.
  • Page 44 DAMAGES. Some states do not allow the OWNER WITH WRITTEN APPROVAL OF exclusion or limitations of incidental or con- US WATER SYSTEMS AND PAYMENT OF sequential damages so the above limitation STANDARD TRANSFER FEE. may not apply to you. This limited warranty...
