PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 COUT1
2 1 C1
3 1 C5
4 1 C8
5 5 C9-C13
6 1 R7
7 1 R9
8 1 R14
9 1 R17
10 1 R19
11 1 U1
Additional Demo Board Circuit Components
1 0 CIN1
2 0 C2, C3
3 0 C4
4 0 C6
5 0 C14
6 0 C15
7 0 C16
8 0 R1
9 0 R2, R10, R20
10 0 R3
11 0 R4
12 0 R5
13 0 R6, R11, R13
14 0 R8, R12, R16, R22
15 0 R15, R18
16 0 R21
17 0 U2
Hardware: For Demo Board Only
1 21 E1-E21
2 1 JP1
3 1 JP1
4 1 J1
5 4 MH1-MH4
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC1818A
PART DESCRIPTION
CAP., POSCAP, 470μF, 4V, D3L
Cap., X5R, 10μF, 50V, 20% 1210
Cap., X7R, 1000pF, 50V, 20% 0603
Cap., X5R, 100μF, 6.3V, 20%, 1210
Cap., X5R, 2.2μF, 10V, 10%, 0805
RES., CHIP, 118k, 1%, 0603
RES., CHIP, 19.6k, 1%, 0402
RES., CHIP, 121k, 1%, 0402
RES., CHIP, 54.9k, 1%, 0402
RES., CHIP, 45.3k, 1%, 0402
IC, LTM8001EY, BGA, 15mmX15mmX3.42mm
CAP., ALUM, 100μF, 50V
Cap., X5R, 1μF, 10V , 20% 0603
Cap., X5R, 10μF, 50V, 20% 1210
Cap., X7R, 100pF, 25V, 10%, 0603
Cap., 0603
Cap., X5R, 2.2μF, 50V, 20%, 1206
Cap., X5R, 10μF, 6.3V, 10%, 1206
RES., CHIP, 121k, 1%, 0603
RES., CHIP, 0Ω, 1206
RES., CHIP, 107k, 1%, 0603
RES., CHIP, 174k, 1%, 0603
RES., CHIP, 100k, 5%, 0603
RES., CHIP, 0603
RES., CHIP, 0Ω, 0603
RES., CHIP, 0402
RES., CHIP, 287k, 1%, 0603
IC, LTM8020EV, LGA, 6.25mmx6.25x2.32mm
TESTPOINT, TURRET, 0.095"
Header, 3 Pins 2mm Ctrs.
SHUNT
CONN, BNC, 5 PINS
STAND-OFF, NYLON 0.5" Tall
MANUFACTURER/PART NUMBER
SANYO, 4TPE470ML
TAIYO YUDEN, UMK325BJ106M
AVX, 06035C102MAT2A
TAIYO YUDEN, JMK325ABJ107MM-T
TAIYO YUDEN, LMK212BJ225KG-T
VISHAY, CRCW0603118KFKEA
VISHAY, CRCW040219K6FKED
VISHAY, CRCW0402121KFKED
VISHAY, CRCW040254K9FKED
VISHAY, CRCW040245K3FKED
LINEAR TECH. LTM8001EY
SUN ELECT, 50CE100LX
TAIYO YUDEN, LMK107BJ105MA-T
TAIYO YUDEN, UMK325BJ106M
AVX, 06033C101KAT2A
TAIYO YUDEN, UMK316BJ225MD-T
TAIYO YUDEN, JMK316BJ106KL-T
VISHAY, CRCW0603121KFKEA
VISHAY, CRCW12060000Z0EA
VISHAY, CRCW0603107KFKEA
VISHAY, CRCW0603174KFKEA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW0603287KFKED
LINEAR TECH. LTM8020EV
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
SAMTEC, 2SN-BK-G
C0NNEX, 112404
KEYSTONE, 8833 (SNAP ON)
