Pulsar PS701205 Manual

1. Technical description.
1.1 General characteristics.
The power supply units are intended for the feeding of alarm system equipment, which requires uninterruptible
supply of 12VDC voltage, provided by 230VAC mains. Their design enables simple switching of the output voltage, within
the range of 12÷15VDC, using a potentiometer. The power supply units are protected against short-circuit, overload and
overvoltage. The PS1501210 power supply unit is additionally equipped with thermal protection.
1.2 Technical parameters.
Dimensions (L x W x H)
Net/Gross weight
Input voltage
Leakage current
Output voltage
Output power
Output current
for t
AMB
Output current
for t
AMB
Output ripple
Short circuit protection
Overload protection
Overvoltage protection
Over temperature
protection
Operation conditions
REMARKS
REMARKS:
Output current (*):
Maximum continuous output current depends of the ambient temperature – refer to graph 1.
PS401203
129 x 98 x 40mm
375g / 395g
85 ÷ 264 V AC
120 ÷ 370 V DC
<0,7mA / 230 VAC
40W
3,0 A*
< 30°C
2,1 A*
= 40°C
<100mV
YES
110% - 150%
output power
YES
NO
-
Enclosed switch-mode power supplies
PS401203, PS701205,
PS1001207, PS1501210
Edition: 2nd from 15.11.2010
Supercedes edition: 1st from 17.07.2010
PS701205 PS1001207
160 x 98 x 39mm 199 x 98 x 39mm
475g / 500g
170 ÷ 264 V AC
<0,7mA / 230 VAC <0,7mA / 230 VAC
12 V ÷ 15V DC (12V factory settings)
70W
5,0 A*
3,5 A*
<100mV
YES
110% - 150%
output power
YES
NO
o o
0 C ÷ 40 C , RH 20 ÷ 90 %, no condensation
-
1
PS1501210
199 x 99 x 50mm
640g / 670g 730g/775g
170 ÷ 264 V AC 85 ÷ 264 V AC
120 ÷ 370 V DC
<0,7mA / 230 VAC
100W 150W
7,0 A* 10,0 A*
4,9 A* 7,0 A*
<100mV <100mV
YES
110% - 130% 110% - 130%
output power output power
YES
NO
-
EN
YES
YES
YES
PFC
