- Page 1 PSBOC1001270 v.1.0 PSBOC 13,8V/7A/OC Caged, switched mode, buffer power supply unit Edition: 1st (10th Mar 2012)
-
Page 2: Table Of Contents
PSBOC1001270 Features: • • 13,8VDC/7A uninterrupted supply FAC technical output indicating AC power loss • • wide range of supply voltage 176÷264VAC FPS technical output indicating PSU failure • • high efficiency 80% FLB technical output indicating battery low •... -
Page 3: Block Diagram
PSBOC1001270 1.2 Block diagram. (fig.1). Fig.1. Block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU (see fig. 2). Element no. Description LED indicating presence of AC power LED indicating presence of DC power LED indicating correct battery voltage FAC- AC absence technical output –... -
Page 4: Specifications
PSBOC1001270 Fig. 2. The view of the PSU. 1.4 Specifications: - electrical specifications (tab.2) - mechanical specifications (tab.3) - operation safety (tab.4) - operating specifications (tab.5) Electrical specifications (tab. 2). Mains supply 176 ÷ 264V AC Current consumption 0,95A@230VAC max. -
Page 5: Installation
PSBOC1001270 Temperature characteristics. Chart 1. Acceptable output current from the PSU depending on ambient temperature. Mechanical specifications (tab. 3). Enclosure dimensions 199 x 97x 42 +23 [mm] (LxWxH) [mm] (+/- 2) Net/gross weight 0,63kg / 0,68kg power supply, technical outputs: Φ0,63÷2,5 I/O PCB : Φ0,41÷1,63... -
Page 6: Operating Status Indication
PSBOC1001270 The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire coat of the power cable shall stick to one side of the ‘PE’ terminal. Using the PSU without a properly made and fully operational shock protection circuit is UNACCEPTABLE! It can cause a device failure or an electric shock. -
Page 7: Technical Outputs
PSBOC1001270 - green LED (Fig.2, element 3) indicates battery voltage level. Under normal status (U > 11,5V) the diode is permanently illuminated. In case of decrease of battery voltage (U < 11,5V) the diode is off. 3.2 Technical outputs The PSU has indication outputs: •... - Page 8 WEEE separately. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt.
