- Page 1 PSAC 04244 v.1.1 PSAC 24VAC/4A/4x1A AC power supply for CCTV Edition: 3 from 29.10.2012 Supersedes the 2 edition from 14.07.2011...
-
Page 2: Table Of Contents
PSAC04244 Features: • power output 4x 1A/24V AC or 27V AC • AW technical output indicating failure • power voltage 230V AC • protections: • 4 outputs protected independently by 1A fuses • SCP short-circuit protection • jumper selectable fuse type: glass fuse or •... -
Page 3: Description Of Psu Components And Connectors
PSAC04244 1.3. Description of PSU components and connectors Tab.1. Terminals and elements of LB4/24V/27V/AW- fuse strip (module). Element no. Description [Fig. 2] L1÷L4 - LEDs (green) indicating L1=AUX1 output status F1÷F4 fuses in AUX circuits, F1=AUX1 etc. COM-U1-U2 AC power input AUX1÷AUX4 –... - Page 4 PSAC04244 Fig.3. The view of the PSU’s panel. Fig.4. The view of the PSU.
-
Page 5: Specifications
PSAC04244 1.4 Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3). Mains supply 230 V AC (-15%/+10%) Current consumption 0,5 A max. Power frequency 50 Hz Power of the S PSU 100 VA max. -
Page 6: Installation
PSAC04244 Operating specifications (tab.6). Operating temperature -10ºC...+40ºC Storage temperature -25ºC...+60ºC Relative humidity 10%...90% without condensation Vibrations during operation unacceptable Impulse waves during operation unacceptable Direct insolation unacceptable Vibrations and impulse waves during transport PN-83/T-42106 2. Installation. 2.1 Requirements The AC/AC power supply is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required for a given country) for 230V/AC interference and low-voltage installations. -
Page 7: Operating Status Indication
PSAC04244 3. Operating status indication. The PSU is equipped with LED indication of operation status. The presence of power at the outputs of the PSU is indicated by the illumination of green LEDs on the PCB of the LB4/24V/27V/AW strip (module). A failure is indicated by a red LED [!] AW. - Page 8 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a five-year warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such defects have been reported within the warranty period (item 1).
