3) Cooling
4) LCD Display + Menu Buttons
5) Earth connection
Installation
Remove all packing materials from the Compact Par 7 Tri. Check that all foam and plastic padding is
removed. Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Damages caused by non-observance are not subject to warranty.
3 4
5
6) IEC Powerconnector + Fuse 1A/250V
7) 3-pin DMX In
8) 3-pin DMX Out
7
6
7
8
Fig. 2
