Summary of Contents for SHOWTEC 42580
- Page 1 MANUAL ENGLISH Compact Par 7 Tri Ordercode: 42580 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Maintenance ................................18 Replacing the Fuse ..............................19 Troubleshooting ................................19 No Light ..................................19 No Response to DMX .............................. 19 Factory Reset ................................19 Product Specifications ..............................21 Dimensions ................................... 22 Ordercode: 42580... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec Compact Par 7 Tri IEC power cable (1,5 m) ... - Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
The installation must always be secured with a safety attachment, e.g. an appropriate safety net or safety cable. When rigging, derigging or servicing the Compact Par, always make sure, that the area below the installation site is secured and that there are not any unauthorized people around. Ordercode: 42580... -
Page 6: Connection With The Mains
UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER NEUTRAL YELLOW/GREEN GREEN GREEN PROTECTIVE GROUND Make sure that the device is always properly connected to the earth! Improper installation can cause serious injuries and/or damage of property! Ordercode: 42580... -
Page 7: Return Procedure
After this period complaints will not be handled anymore. Complaints will only then be considered if the client has so far complied with all parts of the agreement, regardless of the agreement from which the obligation is resulting. Ordercode: 42580... -
Page 8: Description Of The Device
Compact Par 7 Tri Description of the device Features The Showtec Compact Par 7 Tri is a light fixture with high output and great effects. Input voltage: 100-240V AC, 50/60Hz Power consumption: 50W Light source: 7 x 3-in-1 RGB LEDs ... -
Page 9: Backside
Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connect the device to the main power supply. Ordercode: 42580... -
Page 10: Control Modes
14-15 (Built-in programs, Auto, Sound-controlled). This means that you can set your desired operation mode on the master device and all slave devices will react the same as the master device. Multiple Compact Pars (Master/Slave Control) Fig. 03 Ordercode: 42580... -
Page 11: Multiple Compact Pars (Dmx Control)
Do not supply power before the whole system is set up and connected properly. Multiple Compact Pars DMX Set Up Fig. 04 Note : Link all cables before connecting electric power Ordercode: 42580... -
Page 12: Fixture Linking
DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m), FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m). • DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30. Ordercode: 42580... -
Page 13: Control Panel
When no button is pressed for 20 seconds, the display will turn off. To light up the display, you have to press the MODE, SETUP, UP or DOWN button. Once you have pressed the button, the display will light up. Ordercode: 42580... -
Page 14: Menu Overview
Compact Par 7 Tri Menu Overview Ordercode: 42580... -
Page 15: Main Menu Options
, you can use a wide variety of manual color settings. 04) Press the SETUP button to switch between the built-in program menus. Flash Frequency Green Flash Frequency Green Flash Frequency Green Blue Flash Frequency Blue Flash Frequency Blue Flash Frequency Green Blue Flash Frequency Ordercode: 42580... -
Page 16: Auto
02) Turn on the music and the Compact Par will react to the beat of the music. 03) Press the UP/DOWN buttons to set the sound sensitivity. The adjustment range is between , from OFF to high sensitivity. Ordercode: 42580... -
Page 17: Dmx Channels
81-89 Green (255), Blue (150) 90-98 Green (255), Blue (255) 99-107 Green (150), Blue (255) 108-116 Green (50), Blue (255) 117-125 Blue (255) 126-134 Red (50), Blue (255) 135-143 Red (150), Blue (250) 144-152 Red (255), Blue (255) Ordercode: 42580... - Page 18 Program 7 (fantasy change 2) 175-199 Program 8 (red color flow) 200-224 Program 9 (green color flow) 225-249 Program 10 (blue color flow) 250-255 Sound-controlled mode Channel 7 – ID Address ID 1-66 10-19 20-29 30-39 40-49 50-59 60-69 70-79 80-89 90-99 Ordercode: 42580...
-
Page 19: Maintenance
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light output very quickly. Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric power. Ordercode: 42580... -
Page 20: Replacing The Fuse
Suspect three potential problem areas as: the power supply, the LEDs, the fuse. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Compact Par to your Showtec dealer. 03) The fuse. Replace the fuse. See page 19 for replacing the fuse. - Page 21 No light or LEDs cut out • Disconnect the fixture and return it LEDs damaged intermittently to your dealer The power supply settings do not • Disconnect fixture. Check settings match local AC voltage and and correct if necessary frequency Ordercode: 42580...
-
Page 22: Product Specifications
Compact Par 7 Tri Product Specifications Model: Showtec Compact Par 7 Tri Input voltage: 100-240V AC, 50/60Hz Power consumption: DMX linking: 30 pcs Fuse: 1A/250V Dimensions: 275 x 95 x 256 mm (LxWxH) Weight: 2,2 kg Operating and Programming: Signal pin OUT:... -
Page 23: Dimensions
Compact Par 7 Tri Dimensions Ordercode: 42580... - Page 24 ©2017 Showtec...
