Installing Housing; Installing Sd Card; Installing Lens - Dahua IPC-HF5541F-ZE-S3 Quick Start Manual

3.3.2 Installing housing

Use housing if the Camera needs to be installed outdoors, which is to avoid camera damage caused
by water soaking.

3.3.3 Installing SD Card

● SD card slot is available on select models.
● Disconnect the power before installing or removing the SD card.
Press the reset button for 10 seconds to reset the Camera.

3.3.4 Installing Lens

Auto iris socket: Plug the cable of auto iris lens into auto iris socket when the installed lens is auto iris
lens.
Figure 3-4 Install housing
Figure 3-5 Install SD card
10
Quick Start Guide
