Operating Instructions
Air Conditioner
Model No.
Window Unit
CW-LC181AG series
CW-LC181AM series
CW-LC181AR series
CW-XC181AG series
CW-XC181AM series
CW-XC181AR series
Operating Instructions
Air Conditioner
Thank you for purchasing Panasonic Air Conditioner.
Installation instructions attached.
Before operating the unit, read these operating
instructions thoroughly and keep them for future
reference.
Advertisement
Table of Contents
Related Manuals for Panasonic CW-LC181AG Series
Summary of Contents for Panasonic CW-LC181AG Series
- Page 1 CW-LC181AG series CW-LC181AM series CW-LC181AR series CW-XC181AG series CW-XC181AM series CW-XC181AR series Operating Instructions Air Conditioner Thank you for purchasing Panasonic Air Conditioner. Installation instructions attached. Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
-
Page 3: Table Of Contents
CONTENTS Safety Precautions..............1 Parts Identification..............2 FEATURES Display Panel................3 Remote Control .................3 Operational Instructions............4-5 Preparation Before Operation............6 Air-conditioner Installation.............7-10 Air-conditioner Operation.............11-12 Energy Saving Hints..............13 Care and Maintenance.............14 Troubleshooting..............15... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please observe these following safety precautions when using your air conditioner. Failure or negligence in observing these safety precautions could cause fire, electrical shock or personal injury. This sign warns of risk of death or serious injury. WARNING This sign warns of risk of injury or damage to property. -
Page 5: Parts Identification
PARTS IDENTIFICATION 1. Front Grille 2. PM 2.5 Filter 3. Air Filter 4. Remote Control 5. Cabinet 6. Air Inlet Grille (Outdoor Side) 7. Air Outlet Grille 8. Electronic Control Keypad 9. Power Supply Cord 10. Vertical Vane 1. Power supply cord conductors are distinguished according to color. 2. -
Page 6: Features
FEATURES DISPLAY PANEL REMOTE CONTROL Cool Fan Speed Air Swing Timer Off Timer On Power On/Off Button Temperature Buttons Mode Selection Button Fan Speed Button Sleep Selection Button Air Swing Button Timer Selection Button Set Button Cancel Button Powerful Selection Button Maximum distance 7meters Note : 1. -
Page 7: Operational Instructions
OPERATIONAL INSTRUCTIONS INTRODUCTION GENERAL FEATURES DISPLAY DUAL DIGIT 7 SEGMENT DISPLAY The Seven Segment shows: Set Temperature (ST) in Cool Mode and Dry Mode. 'Fn' in Fan Mode. 'E1' when Room Sensor Short or Open. 'E2' when Coil Sensor Short or Open. “SL”... - Page 8 OPERATIONAL INSTRUCTIONS FEATURES : a) Fan Speed Low. b) Swing ON/OFF c) Temp can be set from 16 º C to 30 º C. FAN : In this mode, Compressor will be switched off. High, Medium or Low Fan speed can be selected with the transmitter or Fan key. AUTO FAN SPEED (in Cool Mode) : While increasing room temp: Low fan change to medium when room temp>...
-
Page 9: Preparation Before Operation
PREPARATION BEFORE OPERATION NOTES : WARNING If the unit is not going to be used for an extended period of time, remove the power Ensure that the power plug plug. Otherwise, approximately 2.5W of is securely inserted. electricity will be used even if the unit has A loose plug may cause fire been turned off using the remove control. -
Page 10: Air-Conditioner Installation
A/C INSTALLATION Do not install the unit near a heat source, steam source and flammable gas. Select a location where the power supply is within 1.5 metres (59 Inches). Prepare the installation hole slightly bigger than the actual cabinet size. Ensure that the minimum distances around the unit are maintained as shown below. - Page 11 A/C INSTALLATION INSTALLATION PROCEDURES Remove the cabinet screws. Depending upon the location of the AC LC Series from left (1 nos) and outlet, route the AC cord to either right (1 nos) side. left or right side while installing the XC Series from back side (2 nos).
- Page 12 A/C INSTALLATION REMOVAL OF FRONT GRILLE Please hold the Ribs(Shown in Photo) Remove the front grille. with your thumbs from top and bottom (a) Remove air filter then remove the and push in left direction to open the screw on the front. Grille and to take out filter for cleaning.
- Page 13 A/C INSTALLATION CONDENSED WATER DRAINAGE DRAIN WATER T o achieve maximum cooling efficiency, the airconditioner is designed to splash the condensation water on the condenser coil. Screw In order to avoid the splashing sound, an external drain can be Drain Pan provided by using the following procedure.
-
Page 14: Air-Conditioner Operation
A/C OPERATION OPERATING THE UNIT Start operation by pressing OFF/ON Button. The operation will turn on and the display panel will light up. To stop the operation, press the OFF/ON Button again. POWER The unit will stop operating and the display panel light will turn off. Please note that the OFF indication is as follows : OFF/ON To Start :... - Page 15 A/C OPERATION POWERFUL OPERATION To obtain set temperature quickly: Press POWERFUL. To cancel this operation, press the mode. After POWERFUL is selected, Compressor will turn ON instantly POWERFUL by-passing delay time (if room temp>Preset temp). POWERFUL Fan will run at high speed. SETTING THE OFF/ON TIMER When the air conditioner is in operation: Press the TIMER button.
-
Page 16: Energy Saving Hints
ENERGY SAVING HINTS HELPFUL INFORMATION Auto Restart Control Operation will automatically resume under the previous operation mode. If the unit was set to TIMER mode, operation will not resume automatically. Timer Setting When power failure occurs, the timer setting is cancelled, Once power returns, reset the timer. -
Page 17: Care And Maintenance
Usage over several seasons will reduce performance as the unit becomes dirty. A dirty unit may produce foul odours and dust may clog the dehumidifying drainage. Seasonal inspection is recommended in addition to regular cleaning. Consult Panasonic Authorized Service Centre. -: 14 :-... -
Page 18: Troubleshooting
TROUBLESHOOTING Check the following points before calling for repairs or service if the malfunction persists, BEFORE Please contact Panasonic Authorized Service Centre. If the unit is too noisy If water drips inside the Condition Condition during operation. room. The following sounds are normal during The unit is tilted inward. - Page 20 ACW4PR00601...
