PARTS IDENTIFICATION

3
1
2
1. Power supply cord conductors are distinguished according to color.
2. For your safety and protection, this unit is earthed through the power supply cord.
Please contact the manufacturer or its service dealer or a similarly qualified person if you
want to replace it.
3. This unit is earthed through the power cord.
The wall outlet should be provided with reliable earth wire.
4. The unit should be provided with an individual circuit and the circuit breaker/fuse rating
should be the same as that of the power supply cord and wall outlet.
5
1. Front Grille
2. PM 2.5 Filter
3. Air Filter
4. Remote Control
6
5. Cabinet
7
6. Air Inlet Grille (Outdoor Side)
10
7. Air Outlet Grille
8
8. Electronic Control Keypad
9
9. Power Supply Cord
4
10. Vertical Vane
